Поз.
Артикул
Описание
5
HOUSING P.T.O., TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
5
HOUSING , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401-403,421-423,440-443,445,446 938431 404,424,444 020000, Replaced By: A5422340020
8
SHAFT P.T.O., 401-403 083703 404 000682
11
SPACER TUBE P.T.O.
14
SPACER TUBE
17
CYLINDR. ROLLER BEARING P.T.O.
20
GROOVED BALL BEARING OUTPUT SHAFT
23
SEAL RING STEERING NUT BEARING 75X3 MM
26
SEAL RING HOUSING WITH FLANGE,GASKET AND COVER TO TIMING CASE
29
SPACER TUBE HOUSING WITH FLANGE,GASKET AND COVER TO TIMING CASE
32
GEAR (DRIVE GEAR),P.T.O.
35
NUT DRIVE GEAR TO P.T.O. SHAFT
38
FITTED WASHER INTERMEDIATE FLANGE TO BEARING HOUSING 1,2 MM
38
FITTED WASHER INTERMEDIATE FLANGE TO BEARING HOUSING 1.8 MM
38
FITTED WASHER AS REQUIRED 1.4 MM
38
FITTED WASHER INTERMEDIATE FLANGE TO BEARING HOUSING 1,6 MM
38
FITTED WASHER INTERMEDIATE FLANGE TO BEARING HOUSING 1.0 MM
41
OIL NOZZLE LUBRICATION OF P.T.O.
44
COVER TO PLUG HYDRAULIC PUMP CONNECTION OPENING
47
FLANGE HYDRAULIC PUMP
50
HUB HYDRAULIC PUMP
53
GASKET HYDRAULIC PUMP
56
SCREW BRACKET TO ENGINE
59
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
62
SCREW INTERMEDIATE FLANGE TO BEARING HOUSING
65
SCREW CONTROL VALVE ON CAB BRACKET M 8X25
68
SCREW BRACKET TO EXHAUST PIPE BRACKET
68
SCREW , Replaced By: N304017008024
71
WASHER , Replaced By: N000125008443
71
WASHER EXHAUST MUFFLER TO STRAP
74
WASHER , Replaced By: N009021010209
74
WASHER BRACKET TO COVERING
77
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
80
LOCK WASHER FITTING TO BRACKET
