Поз.
Артикул
Описание
73
AIR LINE CHARGING AIR LINE TO TURBOCHARGER
105
CONNECTOR TURBOCHARGER TO PIPE ELBOW
105
BAFFLE PLATE TURBOCHARGER TO PIPE ELBOW
152
BRACKET CHARGE AIR PIPE TO CYLINDER CRANKCASE
164
SCREW , Replaced By: N304017010002
164
SCREW BRACKET TO SIDE MEMBER
166
WASHER RADIATOR TO RUBBER MOUNTING
168
SPRING WASHER TRANSVERSE CONNECTING PIPE TO CHARGING AIR CONNECTING PIPE
170
NUT
172
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
172
SCREW , Replaced By: N304017008016
174
SPRING WASHER , Replaced By: N000137008212
174
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
188
CHARGING AIR LINE
188
AIR LINE , Replaced By: A4270980307
192
THREADED INSERT ,5 462573
194
THREADED INSERT
200
GASKET CHARGE AIR PIPE TO INTAKE MANIFOLD
200
GASKET , Replaced By: A4471410280
200
GASKET CHARGE AIR PIPE TO INTAKE MANIFOLD
202
SPRING WASHER TRANSVERSE CONNECTING PIPE TO CHARGING AIR CONNECTING PIPE
204
SCREW , Replaced By: N304014010005
204
SCREW CONNECTOR TO REAR SHIFTING ROD
204
SCREW BELL HOUSING TO NMV M 10X135
204
SCREW FROM COUPLING PIECE TO DISTRIBUTOR AT CROSS MEMBER, NOT USED
204
SCREW SUPPORT TO ALTERNATOR
206
SCREW BRACKET TO FRAME SIDE MEMBER
206
HEXAGON HEAD BOLT. SCREW SHIFTING TUBE TO SHIFT LEVER M 10X90
212
NUT
220
FLANGE TO LOCK THE BORE MEANT FOR FLAME START SYSTEM
220
FLANGE , Replaced By: A3760780044
220
FLANGE FLAME START SYSTEM
226
SEAL TO LOCK THE BORE MEANT FOR FLAME START SYSTEM
226
SEAL , Replaced By: A4420780180
228
SPRING WASHER , Replaced By: N000137008212
228
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
230
SCREW PIPE CLAMP
230
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
230
SCREW , Replaced By: N304017008021
230
SCREW CLAMP TO BRACKET AND TO PIPE
232
SCREW PLUG 4/2-WAY VALVE
672
SEAL RING TURBOCHARGER TO PIPE ELBOW
672
SEAL RING
674
CLAMP , Replaced By: A0059972990
674
CLAMP , Replaced By: N000000000675
674
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
676
SCREW PLUG , Replaced By: A0009973532
676
SCREW PLUG OIL COOLER,5 360280
678
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
999
CAP
999
FITTING
999
CHARGING AIR INTERCOOLER , Replaced By: A0010989120
999
CHARGING AIR INTERCOOLER , Replaced By: A0020986220
999
CHARGING AIR INTERCOOLER
999
GASKET
999
GASKET , Replaced By: A4421411380
999
INTAKE MANIFOLD
999
AIR INTAKE PIPE
999
BAFFLE PLATE (CONNECTING LEDGE)
999
BRACKET (CHARGE AIR PIPE),LEFT, 423 - 121553 424 - 001918
999
BUSHING
999
SCREW , Replaced By: A4419905201
999
SCREW BRACKET TO BRACKET, NOT USED
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, REAR
999
BRACKET , Replaced By: A4470980739, +001A6205240340
999
BRACKET CHARGE AIR PIPE, NOT USED
999
FLANGE BRACKET TO SOLENOID,012723
999
SPRING WASHER CAB FLOOR
999
SCREW , Replaced By: N304017006020
999
SCREW LICENSE PLATE TO BRACKET
999
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
999
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
999
NUT , Replaced By: N913023010002
999
NUT PUMP TO BRACKET
999
NUT , Replaced By: N913004006001
999
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
999
COMBINATION BOLT CHARGE AIR PIPE TO INTAKE MANIFOLD M 10X130
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
