Поз.
Артикул
Описание
70
CLUTCH
75
SHIM
77
SCREW , Replaced By: N304017010053
77
SCREW PIPE ELBOW TO BRACKET M 10X50
79
HEX. HEAD. SCREW BUFFER TO CAB, ON VEHICLES LESS DB CAB
81
SCREW BRACKET TO CROSS CONNECTION STRUT
81
SCREW , Replaced By: N304017008034
83
SCREW COVER PLATE TO CROSS MEMBER
85
SPRING WASHER STEERING COLUMN BRACKET TO CAB
87
SPRING WASHER HEATING PIPE TO OIL COOLER
89
CYLINDR. ROLLER BEARING
91
LOCK RING P.T.O.
100
CLUTCH
102
SHIM
104
SCREW BRACKET TO SIDE MEMBER
104
SCREW , Replaced By: N000931014050
104
SCREW , Replaced By: N304017014010
106
SCREW , Replaced By: N304017010053
106
SCREW PIPE ELBOW TO BRACKET M 10X50
108
SCREW , Replaced By: N304017010002
108
SCREW BRACKET TO SIDE MEMBER
110
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
112
SCREW
114
CYLINDR. ROLLER BEARING
116
CYLINDR. ROLLER BEARING
118
SEAL RING
120
GREASE NIPPLE. LUBRICATING NIPPLE LOCK ANGLE SENSOR
122
BREATHER
124
SPRING WASHER BEARING BRACKET TO SIDE MEMBER,4 207081
126
SPRING WASHER STEERING COLUMN BRACKET TO CAB
128
LOCK WASHER BRACKET TO SIDE MEMBER,683254
130
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
132
CLAMPING SLEEVE
999
CLUTCH , Replaced By: A0052501201
999
CLUTCH , Replaced By: A0052501401
999
CLUTCH , Replaced By: A0052501301
999
CLUTCH
999
SCREW CROSS MEMBER TO FRAME
999
SCREW BRAKE BOOSTER ASSEMBLY TO APPARATUS SUPPORT M 10X40,4 338291
