Поз.
Артикул
Описание
413
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
413
SCREW FITTING , Replaced By: A4039971172
452
LINE FROM FEED PUMP TO FILTER
452
LINE FROM FEED PUMP TO FILTER
458
BRACKET DISTRIBUTOR
458
BRACKET DISTRIBUTOR
464
SCREW VALVE TO BRACKET M 8X55
464
SCREW STRAP TO EXHAUST MUFFLER
464
SCREW , Replaced By: N304017008043
468
NUT , Replaced By: N304032008006
468
NUT
480
HEXAGON HEAD BOLT , Replaced By: A0029902704
480
SCREW STRUT TO FRAME M 12X62
480
SCREW BEARING BRACKET TO FRAME
480
SCREW LEFT AND RIGHT CONSOLES TO CAB
480
HEXAGON HEAD BOLT. SCREW REINFORCEMENT TO SIDE MEMBER M 12X55
480
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
480
SCREW , Replaced By: N308676012012
480
SCREW , Replaced By: N308676012018
480
SCREW , Replaced By: N000961012051
480
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
482
LINE FROM FUEL FILTER TO INJECTION PUMP
488
HOSE LEAK LINE, ORDER BY THE METER
488
SCREENING LEAK CONNECTION SEALING AT NOZZLE HOLDER, 314 494961 352 851898 364 022454 366 063371, Replaced By: A0119977782, +002A4030780074
506
LINE FROM INJECTION PUMP OVERFLOW VALVE TO T-FITTING
506
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION
510
LINE FROM FUEL FILTER SAFETY VALVE TO RETURN CONNECTION
581
SEAL RING FUEL LINE TO FEED PUMP
588
BRANCH-OFF FITTING BRACKET TO TIMING CASE COVER
598
CONNECTOR FUEL FEED AND FUEL RETURN TO FUEL DISTRIBUTOR
690
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
713
INTERMEDIATE PIECE , Replaced By: A4470780068
713
CONNECTOR FUEL LEAK,152939
722
BANJO UNION FEED
722
BANJO UNION MANUAL PUMP,D 031294
722
BANJO UNION FUEL LINES AND BREATHING
722
BANJO UNION HOSE WIDTH, / I.D., 8/12 MM
722
BANJO UNION DELIVERY LINE
722
BANJO UNION , Replaced By: N000000000363
724
HOLLOW SCREW
724
HOLLOW SCREW FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
724
HOLLOW SCREW AT FEED PUMP,VB112577
724
HOLLOW SCREW FUEL LINE TO FEED PUMP
724
HOLLOW SCREW 3/2-WAY VALVE,CONNECTION: "2,3"
724
HOLLOW SCREW FUEL LINE TO FEED PUMP
727
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
729
SEAL RING FUEL LINE TO FEED PUMP
729
SEAL RING INJECTION PUMP
729
SEAL RING VALVE TO VALVE,K 025179
729
SEAL RINGTO 000 553 03 05,000 553 18 05,
779
INTERMEDIATE PIECE RETURN LINE TO INJECTION PUMP
779
INTERMEDIATE PIECE (COLLECTING HOSE CONNECTION)
780
NUT
780
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
830
HOSE PLASTIC PIPE,K 223529
830
HOSE LEAK LINE, ORDER BY THE METER
830
HOSE , Replaced By: A0119977782
830
HOSE , Replaced By: A0119977782
830
HOSE , Replaced By: A0119977782
830
HOSE , Replaced By: A0119977782
836
LOOM TIE , Replaced By: A0019978390
836
LOOM TIE , Replaced By: A0019978390
836
LOOM TIE , Replaced By: A0059974390
836
LOOM TIE , Replaced By: A0069973090
836
CABLE TIE. LOOM TIE1140 X 8.9 MM
836
LOOM TIE LINE MOUNTING 280 MM
836
LOOM TIE LINE MOUNTING
838
CONNECTOR FUEL LEAK,152939
838
INTERMEDIATE PIECE , Replaced By: A4470780068
840
NUT. UNION NUT RETURN
999
WASHER EXHAUST MUFFLER TO STRAP
999
LOCK WASHER BRACKET TO SUPPORTING ARM
999
NUT , Replaced By: N304032008006
999
WASHER , Replaced By: N007349008007
999
WASHER
999
SEAL RING SCREW PLUG
999
SCREW SUPPORT TO FENDER
999
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
999
COMBINATION BOLT LEFT & RIGHT CHARGE AIR PIPES TO CYLINDER HEAD M 8X93
999
FITTING WATER SEPARATOR
999
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
999
CLAMPING BRACKET FILTER HOUSING TO PUMP
999
SEPARATOR (WATER SEPARATOR)
999
NUT
999
STUD
999
CLAMPING PIECE FUEL FILTER TO BRACKET,012710
999
FITTING RETURN
999
FITTING FUEL LINE TO HAND PUMP
999
HOLLOW SCREW FUEL LINES TO SOLENOID VALVE
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
INTERMEDIATE PIECE AT INJECTION PUMP
999
LINE FROM FUEL DISTRIBUTOR TO FEED PUMP
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO T-FITTING
999
LINE FROM FUEL FILTER TO INJECTION PUMP
999
LINE FROM FUEL FEED PUMP TO DISTRIBUTOR,062710
999
BRACKET , Replaced By: A4220901241
999
FILTER , Replaced By: A4420900452
999
PLATE LINE MOUNTING,920657
999
LINE
999
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION, NOT USED
999
LINE FROM FEED PUMP TO FILTER, NOT USED
999
LINE , Replaced By: A4470700432
999
LINE FROM FUEL FILTER TO INJECTION PUMP, NOT USED
999
LINE , Replaced By: A4470700332
999
WASHER , Replaced By: N000125008443
