Поз.
Артикул
Описание
11
LINE FRONT LEFT, LATERAL
14
LINE BREATHER LINE TO VALVE
17
LINE FROM SEPARATIN POINT 1 TO SEPARATING POINT 2
20
LINE FROM PIPE LINE TO SEPARATION POINT
23
LINE COOLING WATER LINE TO BREATHER CONNECTION
38
LINE EXHAUST GAS TURBOCHARGER
71
HOLLOW SCREW FEED AND RETURN
74
SEAL RING
86
SPACER TUBE LINE MOUNTING
89
T-FITTING SEPARATION POINT
89
T-FITTING
92
SCREW-IN FITTING LINE CONNECTION TO TRANSMISSION
92
SCREW-IN FITTING OIL PRESSURE SENDER UNIT CONNECTION
95
FITTING LINE CONNECTION TO TRANSMISSION
98
FITTING LINE CONNECTION
110
BRACKET FIXTURE ELECTRIC LINE AT WATER PUMP, SIMPLE PART-PLEASE HAVE SHOP MADE
110
BRACKET COMPRESSED AIR ELBOW
110
BRACKET COOLING WATER LINE TO INTAKE PIPE
110
BRACKET OIL DELIVERY LINE TO TIMING CASE COVER
110
BRACKET COMPRESSED AIR LINE MOUNTING SA 48042
113
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
113
SCREW BRACKET TO SIDE MEMBER M8X20
113
SCREW VALVE TO TRANSMISSION CASE COVER
116
NUT ENGINE MOUNTING M8
118
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
137
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
137
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
161
PIPE CLAMP HALF FUEL LINES TO INTAKE MANIFOLD
161
PIPE CLAMP HALF FUEL LINE TO FUEL LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
CLAMP , Replaced By: N916016038201
999
LOOM TIE
999
LOOM TIE , Replaced By: N916017020000
999
LOOM TIE
999
LOOM TIE , Replaced By: N916017040000
999
LOOM TIE , Replaced By: N916017050000
999
LOOM TIE , Replaced By: N916017025000
999
CLAMP , Replaced By: N916016050201
999
LOOM TIE , Replaced By: N916017070000
999
LOOM TIE , Replaced By: N916017070000
999
FITTING , NOT FOR APPLICABLE TO GERMAN FEDERAL RAILWAY
999
LOOM TIE , Replaced By: N916017050000
999
SEAL RING , Replaced By: A0179971748
999
PIPE LINE , Replaced By: A3015010009
999
HOSE , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3058321223
999
PIPE ELBOW , Replaced By: A3875010356
999
PIPE ELBOW , Replaced By: A3635010556
999
LINE , Replaced By: A4032002752
999
GASKET FLANGE TO PUMP
999
HOSE , Replaced By: A4045000289
999
HOSE , Replaced By: A4045011782
999
HOSE , Replaced By: A4045010782
999
FLANGE , Replaced By: A4079975250
999
PIPE ELBOW EXHAUST GAS TURBOCHARGER, NOT USED
999
HOSE , Replaced By: A4045011682
999
HOSE , Replaced By: A4035016082
999
HOSE , Replaced By: A4045011382
999
HOSE , Replaced By: A4045011382
999
HOSE , Replaced By: A4045011682
999
HOSE , Replaced By: A4215010182
999
LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4042003252
999
LINE FROM CHARGING AIR INTERCOOLER TO PIPE ELBOW, NOT USED
999
OUTLET , Replaced By: A4242000056, +001A3559970149, +001A4079975250, +002N000933010244, +002N912004010102
999
LINE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE OM 424 001504, Replaced By: A4242000652
999
BREATHER PIPE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4470100270
999
LINE FROM CHARGE AIR INTERCOOLER TO BREATHER FITTING, 442-536458 SEE SPECIAL VERSION 082950
999
BRACKET COOLING WATER LINE
999
HOSE
999
LINE
999
FLANGE OIL SEPARATING PIPE
999
SCREW FITTING , Replaced By: A4039971172
