Mercedes N304017006018 - Болт

OM 443 LA 443.980

07 INJECTION SYSTEM - 090 FUEL LINES IL. 2

Поз.
Артикул
Описание
44
A4030700434
LINE UNBENT
47
A4220700466
CLAMPING PIECE LEFT INJECTION LINE TO INTAKE MANIFOLD
53
A4230780385
PIPE BRACKET RIGHT
56
A4220700166
CLAMPING PIECE , Replaced By: A0009951407
56
A4220700266
CLAMPING PIECE
59
A4229950122
CLAMP
59
A4229950042
CLAMP , FROM ENGINE 461719 YEAR OF MANUFACTURE 1998, Replaced By: A0009951407
62
A0009951107
CLAMP DELIVERY LINE
62
A0009951907
CLAMP FOR FIVE LINES
62
A0009951407
CLAMP FOR TWO LINES
65
A4220780186
SHIM , Replaced By: A3660780286, +001A3660780285
65
A4220780386
SHIM , 340.930 FROM ENGINE 084456
68
N910105006002
HEXAGON HEAD BOLT
68
N304017006018
SCREW COVER PLATE TO COVER PLATE M 6 X 12
68
N000933006103
SCREW , Replaced By: N304017006018
999
A4430701633
LINE CYLINDER NO.5
999
A4430701533
LINE CYLINDER NO.4
999
A4430701433
LINE CYLINDER NO.3
999
A4430700733
LINE CYLINDER NO.2
999
A4430700633
LINE CYLINDER NO.1
999
A4230703233
LINE CYLINDER NO.8
999
A4220705833
LINE CYLINDER NO.12
999
A4220705733
LINE CYLINDER NO.9
999
A4220705633
LINE CYLINDER NO.8
999
A4220705533
LINE CYLINDER NO.9
