Поз.
Артикул
Описание
70
SHUTOFF SLIDE
164
WC FLUSHING TRAY
167
DISCHARGE FITTING
170
WATER PUMP WATER FLUSH
173
HOSE PVC 13X3, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
176
CENTRIFUGAL PUMP , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.12.2008
179
HOSE EVACUATION 6X1MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
191
VALVE (CHECK VALVE)
194
ANGLE. FITTING ANGULAR SCREW FITTING 12/R1/2
197
FITTING SCREW-IN FITTING 6/R1/4
197
FITTING SCREW-IN FITTING 12/R1/2
206
DISTRIBUTOR FOR HOSE 6 MM
209
CLAMP12-22
209
CLAMP20-32
212
HOSE5X1,5, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
215
HOSE BLUE, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
218
HOSE NATURAL, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
221
HOSE TRANSPARENT PVC WITH FABRIC 25 X 4,5, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
257
CONTROL STOP. FASTENER CONTROL STOP
269
VALVE (SOLENOID VALVE)
284
DRAIN VALVE
287
HOSE EVACUATION 6X1MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
290
DISTRIBUTOR FOR HOSE 6 MM
293
VALVE
296
ANGLE SCREW-IN FITTING EVACUATION
299
SCREW-IN FITTING EVACUATION
302
SEALING RING EVACUATION
999
COVER
999
DRAIN VALVE
999
SEAL
999
CONNECTION FITTING
999
SCREW FITTING
999
FASTENING FLANGE
999
PIPE PIECE
999
FASTENING FLANGE
