Поз.
Артикул
Описание
806
CABLE CONDUIT
808
ELECTRIC CABLE AT INJECTION PUMP
808
ELECTRIC CABLE AT INJECTION PUMP
808
ELECTRIC CABLE AT INJECTION PUMP
810
GASKETTO 029 545 75 28, A 290167 EXCEPT CODE 805 ALSO INSTALLED IN VEHICLE TO A 290166 WITH CODE 806
810
GASKET WITHE 8 MM
812
CONTACT BUSHING. ROUND PIN BUSHING FROM ELECTRICAL COMPARTMENT TO CONTROL UNIT,SENSOR,ABS SOLENOID VALVE 1,5 MM2
814
GROMMET3.0 MM
816
CONTACT OPEN PINS FASTENER
818
CABLE SHOE. CABLE LUGH2.11/12, A4-2.5 TO 0045424420 / 4520
820
CABLE CONDUIT PROTECTIVE TUBE
822
SCREW CABLE HARNESS MOUNTING
822
SCREW CLAMP ON BRACKET
822
SCREW STOP TO BATTERY CASE
822
SCREW SWITCHING APPARATUS TO BRACKET M 8X25
822
SCREW CLAMP TO EXHAUST PIPE AND TO FLEXIBLE METAL TUBE M 8X25
822
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
824
WASHER EXHAUST MUFFLER TO STRAP
826
NUT AT INJECTION PUMP
828
SEAL RING CABLE PASSAGE
830
ANGLE LINE MOUNTING
832
CLAMP DELIVERY AND SUCTION LINES TO FRAME
832
CLAMP SENSOR CABLE TO FRONT AXLE
834
SCREW LICENSE PLATE TO BRACKET
836
NUT SPRING-LOADED PUSH ROD
838
SENDER UNIT COOLING WATER
840
SEALING RING. SEAL RING ENGINE BREATHING
842
ELECTRIC CABLE TEMPERATURE SENDER UNIT CONNECTION
842
ELECTRIC CABLE TEMPERATURE SENDER UNIT CONNECTION
844
BOOT CABLE HARNESS EXTENSION
846
PLUG SOCKET PRESSURE SWITCH SCREW-CONNECTION TO M 24X1
848
NUT PRESSURE SWITCH SCREW-CONNECTION M 24X1,5 129167
850
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 24X1,5 129167
852
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
854
BRACKET LINE MOUNTING
856
BRACKET LINE MOUNTING
858
BRACKET LINE MOUNTING
860
CLAMP HYDRAULIC LINE TO SIDE MEMBER,RB012797
860
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
862
SPACER TUBE SUPPORT TO INTAKE PIPE
864
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
864
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
864
SCREWM 10X20
864
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
864
SCREW LEVER TO ENGINE CONTROL SHAFT
864
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
866
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
866
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
866
SCREW CABLE HARNESS MOUNTING
868
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
868
NUT ENGINE MOUNTING M8
868
HEXAGON NUT. NUT , Replaced By: N913023008002
870
SENDER UNIT CHARGE AIR PRESSURE
872
FITTING CHARGE AIR PRESSURE
872
FITTING CHARGE AIR PRESSURE
874
SEAL RING
874
SEAL RING , 001778
874
SEAL RING TEMPERATURE GAUGE SENDER UNIT
876
ELECTRIC CABLE CHARGE AIR PRESSURE, TO BE ADAPTED DURING ASSEMBLY
876
ELECTRIC CABLE CHARGE AIR PRESSURE
878
ELECTRIC CABLE CHARGE AIR PRESSURE, TO BE ADAPTED DURING ASSEMBLY
878
TS PLUG. PLUG PARTS KIT
880
CABLE SHOE. CABLE LUGH2.11/12, A4-2.5 TO 0045424420 / 4520
882
CONTACT OPEN PINS FASTENER
884
CHARGE AIR TEMP.SENSOR CHARGE AIR TEMPERATURE SENSOR, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
884
CHARGE AIR TEMP.SENSOR , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0005357530
886
SENDER UNIT CHARGE AIR TEMPERATURE SENSOR
888
FITTING TWO-WAY VALVE "12",4 4121264 691315
890
SEAL RING
892
SEAL RING , 001778
894
ELECTRIC CABLE CHARGE AIR TEMPERATURE SENSOR
894
ELECTRIC CABLE CHARGE AIR TEMPERATURE SENSOR
934
ELECTRIC CABLE OIL PRESSURE GAUGE SENDER UNIT
934
ELECTRIC CABLE OIL PRESSURE GAUGE SENDER UNIT
934
ELECTRIC CABLE OIL PRESSURE SENDER UNIT CONNECTION
936
PLUG
938
CONTACT SPRING
942
CONTACT OPEN PINS FASTENER
944
CABLE SHOE. CABLE LUGH2.11/12, A4-2.5 TO 0045424420 / 4520
946
SCREWED CONNECTION OIL PRESSURE SENDER UNIT CONNECTION
948
SCREW-IN FITTING OIL PRESSURE SENDER UNIT CONNECTION
950
INTERMEDIATE PIECE SENDER UNIT TO CYLINDER CRANKCASE
950
INTERMEDIATE PIECE SENDER UNIT TO CYLINDER CRANKCASE
952
SEALING RING. SEAL RING ENGINE BREATHING
954
OIL LINE OIL FEED LINE
957
UNION NUT OIL FEED LINE
958
CUTTING RING. GLAND LINE CONNECTION
994
GROMMET3.0 MM
995
CONTACT OPEN PINS FASTENER
996
CABLE SHOE. CABLE LUGH2.11/12, A4-2.5 TO 0045424420 / 4520
998
LOOM TIE
998
LOOM TIE LINE MOUNTING
998
LOOM TIE LINE MOUNTING 280 MM
999
BOOT
999
BOOT , Replaced By: A1239971681
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CABLE SHOE
999
CLAMP
999
SCREW SHOCK ABSORBER TO BOTTOM BRACKET
999
CLAMP
999
SEAL RING CABLE PASSAGE
999
GROMMET ELECTRIC CABLE
999
NUT
999
CABLE GUIDE
999
BRACKET
999
SCREW LOCKING BOLT M8X65,V 208920
999
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
999
BUFFER LEFT, FROM CHASSIS: 010 077937
999
PART NAME MISSING
999
SPACER TUBE OIL-PRESSURE-GAUGE-SENDER-UNIT CABLE, TO BE ADAPTED DURING ASSEMBLY
999
ANGLE
999
BRACKET AT CYLINDER BLOCK, REAR
999
BRACKET ,000022
999
BRACKET BELL HOUSING
999
ANGLE SHIFTING DOME
999
SPACER TUBE , Replaced By: A2089910040
999
COVER
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
BRACKET ELECTRIC CABLE TO OIL COOLER
999
COVER TIMING CASE
999
SCREW
999
COVER
999
GASKET
999
BRACKET INTAKE LINE TO CYLINDER HEAD COVER
999
PROTECTIVE TUBE CONTROL-DEVICE-TO-PLUG-CONNECTION ELECTRIC CABLE
999
PROTECTIVE CAP PROTECTIVE TUBE
999
BRACKET
999
BRACKET LINE MOUNTING
999
GROUND CABLE FROM STARTING MOTOR TERMINAL 31 TO CABLE TERMINAL
999
ELECTRIC CABLE FROM STARTING MOTOR TERMINAL 30 TO CABLE TERMINAL
999
ELECTRIC CABLE FROM ALTERNATOR TO STARTING MOTOR/PROTECTION AGAINST CONSEQUENTIAL DAMAGE
999
GROUND CABLE FROM ALTERNATOR TO STARTING MOTOR/PROTECTION AGAINST CONSEQUENTIAL DAMAGE
999
ELECTRIC CABLE FROM ALTERNATOR TO PROTECTION AGAINST CONSEQUENTIAL DAMAGE,708903
999
BRACKET ELECTRIC CABLE TO OIL PAN
999
COVER WITH AIR INTAKE. COVER
999
CABLE CONDUIT
999
CABLE CONDUIT
999
CABLE CONDUIT
999
CABLE CONDUIT
999
CABLE CONDUIT
999
CABLE CONDUIT
999
BRACKET FIXTURE ELECTRIC LINE AT WATER PUMP, SIMPLE PART-PLEASE HAVE SHOP MADE
999
WASHER FROM TERMINAL BOX TO CHARGING AIR PIPE
999
BRACKET ELECTRIC CABLE MOUNTING
999
BRACKET ELECTRIC CABLE
999
GROUND CABLE FROM STARTING MOTOR TERMINAL 31 TO CABLE TERMINAL
999
GROUND CABLE FROM STARTING MOTOR TERMINAL 30 TO CABLE TERMINAL
999
GROUND CABLE FROM ALTERNATOR TO STARTING MOTOR/PROTECTION AGAINST CONSEQUENTIAL DAMAGE,875390
999
GROUND CABLE FROM ALTERNATOR TO STARTING MOTOR/PROTECTION AGAINST CONSEQUENTIAL DAMAGE,875390
999
PROTECTIVE CAP PROTECTIVE TUBE
999
SHIM ELECTRIC CABLE TO CLAMPING PIECE
999
BRACKET AT CYLINDER CRANKCASE
999
BRACKET OIL LINE TO AIR COMPRESSOR, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
THREADED CHUCK RPM SENSOR ON TIMING CASE
999
CLAMPING PIECE CABLE HARNESS MOUNTING
999
FUSE CABLE HARNESS MOUNTING
999
SCREW
999
PLUG CABLE HARNESS MOUNTING
999
PART NAME MISSING. CAP CABLE HARNESS MOUNTING
999
PART NAME MISSING. CAP CABLE HARNESS MOUNTING
999
SCREW BRACKET TO SIDE MEMBER M8X20
999
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
999
WASHER , Replaced By: N000125008443
999
WASHER VIBRATION ABSORBER TO BRACKET
999
CYLINDRICAL HEAD SCREW. SCREW FASTENING CLAMP ON HOLDER
999
END-TYPE TERMINAL
999
SCREW BRAKE SHAFT TO THRUST SHACKLE
999
SCREW RUBBER MOUNTING TO ENGINE M 12X35
999
SCREW. HEXAGON HEAD BOLT RELAY TO BRACKET M5X16
999
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
999
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
999
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
999
SCREW , Replaced By: N000000000436
999
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
999
NUT , Replaced By: N913023006001
999
HEXAGON NUT. NUT LINE TO SIDE MEMBER
999
HEXAGON NUT. NUT , Replaced By: N913023008002
999
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
999
CLAMP FROM DISTRIBUTOR TO CYLINDER
999
CLAMP LINE TO SIDE MEMBER
999
CLAMP BATTERY CABLE MOUNTING
999
CLAMP ELECTRIC CABLE TO OIL PAN
999
CLAMP LINES TO BRACKET
999
CLAMP WIRING HARNESS FIXTURE AT AIR COMPRESSOR COOLANT LINE
999
CLAMP OIL DIPSTICK TO RADIATOR
999
CLAMP OIL LINE TO BRACKET
