Поз.
Артикул
Описание
6
INTAKE MANIFOLD
6
INTAKE MANIFOLD
6
INTAKE MANIFOLD
6
INTAKE MANIFOLD
6
INTAKE MANIFOLD
6
INTAKE MANIFOLD
6
INTAKE MANIFOLD
12
INTAKE MANIFOLD , Replaced By: A4071403801
12
INTAKE MANIFOLD ,010583
12
INTAKE MANIFOLD
75
THREADED INSERT
75
THREADED INSERT ,5 462573
75
THREADED INSERTTO 407 140 18 01/23 01
75
THREADED INSERT
75
THREADED INSERT
75
THREADED INSERT
75
THREADED INSERT
75
THREADED INSERT
75
THREADED INSERT
75
THREADED INSERT
78
GASKET INTAKE MANIFOLD TO CYLINDER HEAD
78
GASKET , Replaced By: A4031411080
78
GASKET , Replaced By: A4031411080
78
GASKET , Replaced By: A4031411180
78
GASKET , Replaced By: A4421410480
78
GASKET , Replaced By: A4421411780
78
GASKET INTAKE MANIFOLD TO CYLINDER HEAD
78
GASKET INTAKE MANIFOLD
78
GASKET INTAKE MANIFOLD TO CYLINDER HEAD
81
SCREW FUEL LINE TO INTAKE MANIFOLD M 8X98
81
SCREW VALVE BODY ASSEMBLY TO TRANSMISSION M 8X55
81
SCREW BRACKET TO CROSS MEMBER
81
SCREW
81
SCREWM 8X125, FROM ENGINE 706242-999999 YEAR OF MANUFACTURE 1982-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
81
SCREW BRACKET TO RIGHT SIDE MEMBER,5 434014
81
SCREW SUPPORT TO INTAKE PIPE
81
SCREW BEARING BRACKET TO CAB M 8X30
81
HEXAGON HEAD BOLT. SCREW EXHAUST PIPE TO MUFFLER
81
COMBINATION BOLT BRACKET TO LONGITUDINAL INTAKE PIPE
81
COMBINATION BOLT INTAKE MANIFOLD TO CYLINDER HEAD M 8X93
81
SCREW , Replaced By: A0069909101
81
SCREW WIRING HARNESS FIXTURE AT AIR PIPE
81
SCREW FRONT AXLE REGULATING SOLENOID VALVE
81
SCREW INTAKE MANIFOLD TO CYLINDER HEAD M8 X 108
81
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET M 8X95
81
SCREW , Replaced By: N304014008007
81
SCREW , Replaced By: N304014008021
81
SCREW , Replaced By: N304017008067
81
SCREW , Replaced By: N304014008009
81
SCREW FILTER BOWL TO FILTER HEAD M 8X90,841477 ONLY FOR USE WITH BOSCH DOUBLE FILTER
81
COMBINATION BOLT , Replaced By: A0079902001
81
COMBINATION BOLT BRACKET WITH INTAKE MANIFOLD TO CYLINDER HEAD,021787
81
COMBINATION BOLT , Replaced By: A0079902501
81
COMBINATION BOLT , Replaced By: A0079902101
81
COMBINATION BOLT , Replaced By: A0079902201
81
SCREW 3/2-WAY VALVE TO BRACKET
81
SCREW INTAKE MANIFOLD TO CYLINDER HEAD M 8X93
81
SCREW CONTROL VALVE
84
SPRING WASHER , Replaced By: N000137008212
84
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
87
HEXAGON HEAD BOLT. SCREW REFRIGERANT COMPRESSOR TO SUPPORT M8 X 90
87
SCREW REAR AXLE REGULATING SOLENOID VALVE M 8X95
87
SCREW , Replaced By: N910105008007
87
SCREW THERMOSTAT HOUSING TO WATER PUMP M 8X38
90
SPACER SLEEVE. SPACER TUBE FAN SHROUD TO RADIATOR,4 1619994 428844
90
SPACER TUBE SHAPED HOSE ON AIR INTAKE PIPE
90
SPACER TUBE , Replaced By: A4602910350
90
BUSHING APPARATUS PLATE 9 MM, TO BE ADAPTED DURING ASSEMBLY
222
SCREW PLUG 4/2-WAY VALVE
225
SEAL RINGTO 001 431 72 14
225
SEAL RING PNEUMATIC VALVE
225
SEAL RING , Replaced By: N007603010110
228
SCREW PLUG , Replaced By: N000908022011
228
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
228
SCREW PLUG BELL HOUSING TO 620 251 07 01,620 251 16 01, 426,427,428,521,522 5 095724 532 5 104253
228
SCREW PLUG TO LOCK HEATER PLUG BORE, NOT USED
231
SEAL RING TEMPERATURE GAUGE SENDER UNIT
231
SEAL RING
231
SEAL RING LINE CONNECTION
234
SCREW PLUG , Replaced By: N000908022011
234
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
234
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
234
SCREW PLUGROCKINGER,TYP 59 U150
234
SCREW PLUG 3/2-WAY VALVE,CONNECTION:,5 363121
237
SEAL RING LINE CONNECTION
237
SEAL RING PRESSURE CONNECTION TO AIR COMPRESSOR
237
SEAL RING LINE CONNECTION
237
SEAL RING LINE CONNECTION
249
LOCKING CAP TO PLUG INTAKE MANIFOLD AT AIR COMPRESSOR CONNECTION
249
LOCKING CAP
249
LOCKING CAP TO LOCK COOLING WATER BOTTOM OUTLET
252
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
252
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
252
LOOM TIE
252
CLAMP , Replaced By: N916017011001
252
CLAMP , Replaced By: N000000000665
252
CLAMP , Replaced By: A0069970590
270
BREATHER PIPE ,022581
270
BREATHER PIPE
270
BREATHER PIPE
273
INTAKE PIPE
276
INTAKE PIPE AIR COMPRESSOR
276
INTAKE PIPE
279
BRACKET
282
CLAMP HOSE TO FLANGE AND TO VALVE
285
SCREW LICENSE PLATE TO BRACKET
285
SCREW , Replaced By: N304017006020
288
NUT , Replaced By: N910113006001
288
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
294
FITTING AIR COMPRESSOR,CONNECTION: "10"
297
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
297
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
300
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
999
LOCKING CAP
999
INTAKE MANIFOLD
999
INTAKE MANIFOLD ,010582
999
SPACER TUBE , Replaced By: A4602910350
999
GASKET TO PLUG INTAKE MANIFOLD, NOT USED
999
INTAKE MANIFOLD
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW , Replaced By: N304014008021
