Поз.
Артикул
Описание
4
GEAR DRIVE GEAR ON CAMSHAFT
8
SCREW CONNECTOR TO REAR SHIFTING ROD
8
SCREW , Replaced By: N304017010047
12
COMPRESSOR
28
HOUSING
36
SPACER TUBE
40
GASKET OIL FILTER TO CYLINDER CRANKCASE
40
GASKET OIL FILTER TO CYLINDER CRANKCASE
48
CAP TO PLUG AIR COMPRESSOR OPENING,128243
64
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
68
SCREW PIPE CLAMP
68
SCREW STOP TO BATTERY CASE
68
SCREW , Replaced By: N304017008021
72
SPRING WASHER , Replaced By: N000137008212
72
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
76
CAP COVER TO AIR COMPRESSOR HOUSING
80
GASKET COVER TO AIR COMPRESSOR HOUSING
84
FLANGE ON POWER STEERING PUMP END
84
FLANGE , Replaced By: A4421311342
88
BUSHING
92
SEAL RINGTO 388 476 71 69
96
CAP TO PLUG AIR COMPRESSOR,REAR
100
GASKET COVER TO TIMING CASE, Replaced By: A0259976947
100
FLANGE GASKET COVER TO TIMING CASE
104
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
104
SCREW BRACKET TO SIDE MEMBER M10X35
108
LOCK WASHER , Replaced By: N912004010102
108
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
112
FLANGE DRIVE END
116
BUSHING DRIVE END
116
BUSHING DRIVE END
120
LOCK BEARING FLANGE IN TIMING CASE & AIR COMPRESSOR HOUSING,RESP.
124
CRANKSHAFT , Replaced By: A4421300314
132
GROOVED PIN
136
ROLL PIN
136
CLAMPING SLEEVE
140
DRIVE GEAR
144
SCREW DRIVE GEAR TO CRANKSHAFT
148
CONNECTING ROD , Replaced By: A4421310217
156
CYLINDER LINER WITH PISTON,AIR-COOLED, 972,973,977,978,979 650333
164
PISTON PIN
164
PISTON PIN
168
SNAP RING
168
SNAP RING
172
PISTON RING GROOVE II
172
PISTON RING , Replaced By: A0011311311
172
PISTON RING GROOVE I
176
PISTON RING GROOVE I
176
PISTON RING GROOVE II
176
PISTON RING , Replaced By: A0011311411
180
PISTON RING GROOVE III
180
PISTON RING , Replaced By: A0011311511
184
CYLINDER HEAD LESS DISC VALVE,890022
192
THREADED INSERT REPAIR SIZE, TO BE ADAPTED DURING ASSEMBLY
196
GASKET OIL FILTER TO CYLINDER CRANKCASE
196
GASKET OIL FILTER TO CYLINDER CRANKCASE
200
SCREW DISC VALVE TO CYLINDER HEAD
204
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
212
VALVE AIR COMPRESSOR CYLINDER HEAD, 972,973,977,978,979 650333
212
VALVE
220
GASKET DISC VALVE TO CYLINDER HEAD
220
GASKET INTERMEDIATE PLATE TO CYLINDER HEAD, 972,973,977,978,979 650333
220
GASKET INTERMEDIATE PLATE TO CYLINDER HEAD, 972,973,977,978,979 650333
220
GASKET DISC VALVE TO CYLINDER HEAD
224
GASKET CYLINDER HEAD TO CYLINDER LINER, 972,973,977,978,979 650333
236
FITTING AIR-COMPRESSOR CYLINDER-HEAD COOLING WATER CONNECTIONS
240
SEAL RINGTO 376 131 74 01
272
SCREW CLUTCH TO FLYWHEEL,760271
276
SCREW INJECTION PUMP DRIVE TO TIMING CASE M 8X140
280
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
280
SPRING WASHER , Replaced By: N000137008212
999
SEALING COMPOUND TUBE OF SEALANT, WITH REAR CRANKSHAFT SEALING TO BE REWORKED,UP TO ENGINE 283201
999
SEALANT , Replaced By: A0019892920
999
SEALING COMPOUND TIMING CASE COVER TO TIMING CASE, UP TO ENGINE 978,979 331710 YEAR OF MANUFACTURE 1994
999
PARTS KIT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4411300220
999
CRANKSHAFT , 972,973,977,978,979 650333888000, Replaced By: A4421300614, +001A4421300445, +001A0001321410
999
FLANGE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 888000, Replaced By: A4421300445
999
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312080
999
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312880, +001A4429940060
999
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312280
999
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
999
COMPRESSOR
999
COMPRESSOR , TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
LINE FROM CRANKCASE COOLING WATER INLET TO AIR COMPRESSOR
999
LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4472003552
999
SCREW PLUG , Replaced By: N000908026008
999
SCREW , Replaced By: N304017008033
999
WASHER
999
SEAL RING INJECTION PUMP
999
SCREW , Replaced By: N910105008019
999
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
CLAMP , Replaced By: N916016010211
