Поз.
Артикул
Описание
15
PITMAN ARM
15
PITMAN ARM , MECHANICAL STEERING UP TO IDENT NO. 152645,POWER STEERING UP TO IDENT NO. 152683, Replaced By: A6014630401, +001A6013380001, +001A6014600705
15
PITMAN ARM ,166248, Replaced By: A6014630501, +001A6014600705
22
NUT DRAG LINK TO LEVER
30
BOOT UNIVERSAL JOINT COVERING,P 235580
30
BOOT ,P 235579, Replaced By: A6114620096, +001A6014620297
33
LOOM TIE LINE MOUNTING
36
CONSOLE (STEERING BRACKET)
42
FITTED SCREW STEERING TO STEERING BRACKET
48
SCREW BRACKET TO FRAME SIDE MEMBER
54
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
57
LOCK WASHER OIL PUMP TO TRANSMISSION CASE
60
SCREW REAR EXHAUST PIPE TO MUFFLER
60
SCREW SUPPORT TO CROSS MEMBER M 10X28
60
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
68
NUT STRAP TO BRACKET
68
NUT , Replaced By: N910113010000
74
WASHER , Replaced By: N000125010532
74
WASHER RADIATOR TO RUBBER MOUNTING
90
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
90
BRACKET , Replaced By: A3184923441
90
BRACKET , Replaced By: A3184923841
98
UNIVERSAL JOINT , Replaced By: A3094600157
98
UNIVERSAL JOINT ,370112
98
UNIVERSAL JOINT ,370112
98
UNIVERSAL JOINT ,370111
98
UNIVERSAL JOINT ,P 292961
98
UNIVERSAL JOINT ,370112
106
SCREW UNIVERSAL JOINT TO STEERING COLUMN M 8X38,5 463984
112
NUT STRAP TO BRACKET
120
DRAG LINK
120
DRAG LINKLEMFOERDER, USE LOCK NUT FOR HEXAGON SOCKET : A 003 990 78 51
120
DRAG LINK , Replaced By: A3094603105
120
DRAG LINK , Replaced By: A3094603205
120
DRAG LINK , Replaced By: A6014601505
121
DRAG LINK END ADJUSTABLE EHRENREICH
121
DRAG LINK ENDLEMFOERDER
122
DRAG LINK END
122
DRAG LINK END , Replaced By: A0004608648, +001A0039907851
124
CLAMP DRAG LINK END TO DRAG LINK
124
CLAMP DRAG LINK END TO DRAG LINK
125
SCREW
125
SCREW , Replaced By: N308676010023
125
SCREW , Replaced By: N000961010031
126
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
127
HEXAGON NUT
127
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
127
NUT , Replaced By: N308673010000
127
NUT , Replaced By: N910113010002
128
NUT DRAG LINK TO LEVER SELF-LOCKING
128
NUT M14X1,5 MM
129
COTTER PIN LEVER TO SUPPORT
130
STEER. COLUMN JACKET TUBE , UP TO IDENT NO. 214382 AND FROM IDENT NO. 500001-533801
130
STEER. COLUMN JACKET TUBE
130
STEER. COLUMN JACKET TUBE ,029082, Replaced By: A6014600116, +001A6014620297
130
STEER. COLUMN JACKET TUBE , Replaced By: A6114600216
136
SCREW , Replaced By: N304017008016
136
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
138
WASHER BRACKET TO CAB REAR PANEL
138
WASHER , Replaced By: N009021008213
138
WASHER BRACKET TO LEFT SIDE MEMBER
142
SEAL COVERING TO STEERING COLUMN JACKET TUBE,029082
142
COVERING STEERING COLUMN JACKET TUBE TO FLOOR PLATE,P 235580
142
SEAL COVERING TO STEERING COLUMN JACKET TUBE,029082
142
SEAL STEERING COLUMN JACKET TUBE TO FLOOR PLATE,P 235579
148
CLAMP STEERING COLUMN JACKET TUBE TO INSTRUMENT PANEL
148
CLAMP , Replaced By: A6119950410
154
SCREW , Replaced By: N304017008027
154
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
160
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
166
BUSHING STEERING COLUMN JACKET TUBE
172
RING STEERING COLUMN JACKET TUBE
190
STEERING SHAFT
190
STEERING SHAFT ,143658214382
190
STEERING SHAFT ,143658214382
190
STEERING SHAFT
196
FOLLOWER , UP TO IDENT NO. 214382 AND FROM IDENT NO. 500001-533801
202
SCREW DIODE CASE TO OPERATING UNIT CASE
219
SWITCH STARTING
222
IGNITION SWITCH
222
IGNITION SWITCH
225
VALVE
228
TUMBLER WITH LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
228
TUMBLER , Replaced By: A6014600304
230
TUMBLER WITHOUT LOCK UNDEFINED
231
KEYYMOS, STATE LOCK NUMBER WHEN ORDERING
231
KEYHUF, STATE LOCK NUMBER WHEN ORDERING
232
KEY BLANK HUF
232
KEY BLANK YMOS
234
COVER
234
COVER , Replaced By: A1234620523
240
CLAMPING PIECE , Replaced By: A1154600322
240
CLAMPING PIECE
246
SCREW CONNECTOR
290
STEERING WHEEL , UP TO IDENT NO. 214382 AND FROM IDENT NO. 500001-533801 NO.8316INO.7C52INO.7B90INO.9051I II I
290
STEERING WHEEL , UP TO IDENT NO. 214382 AND FROM IDENT NO. 500001-533801 NO.8316INO.7C52INO.7B90INO.9051I II I
290
STEERING WHEEL
290
STEERING WHEEL , UP TO IDENT NO. 214382 AND FROM IDENT NO. 500001-533801 NO.8316INO.7C52INO.7B90INO.9051I II I
292
CONTACT PIECE STEERING WHEEL
295
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
300
BADGE STEERING WHEEL, NO.8316INO.7C52INO.7B90INO.9051I II I
304
SIGNAL PLATE STEERING WHEEL, NO.8316INO.7C52INO.7B90INO.9051I II I
308
CONTACT PLATE STEERING WHEEL
312
HOSE FROM STEERING LOCK TO VACUUM PUMP LINE 830 MM
312
HOSE FUEL LINE, ORDER BY THE METER
316
PIPE LINE FROM CHECK VALVE DISTRIBUTOR TO SUPPLY TANK 500 MM, ORDER BY THE METER 114.010 FROM CHASSIS 031062,114.015,017 FROM CHASSIS 033609,114.021 FROM CHASSIS 001552,114.022 FROM CHASSIS 000843,114.023 FR OM CHASSIS 000001 115.010 FROM CHASSIS 034113,115.015 FROM CHASSIS 032215 114.010,021,022 UNTIL PRODUCTION STOP, 114.011 UP TO CHASSIS 108425, 114.015,017 UP TO CHASSIS 245853, 114.023 UP TO CHASSIS 100866 AND FOOTN.63
316
HOSE , ORDER BY THE METER
320
HOSE *** 30 MM
322
LINE. HOSE FROM VACUUM CONTROL VALVE TO PASSENGER COMPARTMENT 4 MM, ORDER BY THE METER
322
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
324
LOOM TIE LINE MOUNTING 280 MM
328
GROMMET VACUUM LINE THRU ENGINE HOOD CLAMP
328
GROMMET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.941504, Replaced By: A6019973681
999
BOOT FIXED PART OF JOINT,294908
