Поз.
Артикул
Описание
128
VALVE SOLENOID VALVE,5 450429 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
128
VALVE , Replaced By: A0049975736
128
VALVE (3/2-WAY SOLENOID VALVE) EKS
131
VALVE PARTTO 004 997 00 36,5 757289 AUSSERDEM EINGEBAUT IN 5 759173
134
SEAL RING24X2 MM
137
SEAL RINGWABCO
140
PROTECTIVE CAPWABCO
143
SEAL RING VALVE TO VALVE
146
SEAL RINGTO 000 429 24 30
149
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
152
BRACKET 3/2-WAY SOLENOID VALVE
155
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
155
SCREW , Replaced By: N304017008016
158
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
161
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
164
WASHER BRACKET TO LEFT SIDE MEMBER
164
WASHER , Replaced By: N009021008213
167
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
170
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
173
FITTING LINE CONNECTION
176
FITTING 3/2-WAY SOLENOID VALVE,CONNECTION: "20",5 766895, 5 806950
179
SEAL RING 3/2-WAY VALVE
182
HOLLOW SCREW HEATING CONNECTION
185
HOLLOW SCREW LINE CONNECTION
188
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
188
SEAL RING SRREW PLUG
188
SEAL RING LINE CONNECTION
191
SCREW. UNION SCREW , Replaced By: A0009973734
191
SCREW. UNION SCREW LINE CONNECTION
194
VALVE (3/2-WAY SOLENOID VALVE)
197
REPAIR KIT 3/2-WAY SOLENOID VALVE
200
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
203
NUT HORN TO BRACKET M8
206
SCREW. UNION SCREW LINE CONNECTION
206
SCREW. UNION SCREW , Replaced By: A0009973734
224
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
999
VALVE (QUICK-RELEASE VALVE)
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
999
SCREW. UNION SCREW LINE CONNECTION
999
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
999
VALVE (QUICK-RELEASE VALVE) WABCO
999
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
999
SEAL RING LINE CONNECTION
999
HOLLOW SCREW FITTING SHIFTING CYLINDER
