Поз.
Артикул
Описание
29
CLAMP CABLE HARNESS MOUNTING
29
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
29
CLAMP LINE MOUNTING
29
CLAMP PIPE ON FAN SHROUD
29
CLAMP , Replaced By: N000000001045
29
CLAMP , Replaced By: N916016010211
29
CLAMP ,K 147121, Replaced By: N000000000319
29
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
29
MOUNTING CLAMP MOUNTING USED FOR COMPRESSED AIR LINES RSGU 20/15
29
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
32
CLAMP HOSE TO FITTING AND TO OIL TANK
32
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
32
CLAMP MOUNTING USED FOR COMPRESSED AIR LINES 32/20 MM
35
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
35
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
35
SCREW COVER PLATE TO COVER PLATE M 6 X 12
35
SCREW SPRING BRACKET TO FRAME
35
SCREWM X 110
35
SCREW LICENSE PLATE TO BRACKET
35
SCREW BRACKET TO CROSS CONNECTION STRUT
35
SCREW , Replaced By: N308676012012
35
SCREW , Replaced By: N304017006020
35
SCREW , Replaced By: N304017006018
35
SCREW PIPE CLAMP
35
SCREW CAB FLOOR COVERING M 6X25
35
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
38
WASHER COMPRESSED AIR LINE TO BRACKET
38
WASHER BRACKET TO CAB REAR PANEL
38
WASHER COVERING TO CYCLONE AIR TRAP
38
WASHER BRACKET TO LEFT SIDE MEMBER
38
WASHER , Replaced By: N009021008213
38
WASHER , Replaced By: N009021006208
38
WASHER , Replaced By: N009021005205
38
WASHER , Replaced By: N009021004207
38
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
41
WASHER
47
NUT STRAP TO BRACKET
47
NUT PUMP TO BRACKET
47
NUT , Replaced By: N913004006001
47
NUT HEATING PIPE TO BRACKET
47
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
47
NUT SPRING-LOADED PUSH ROD
47
NUT
155
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
155
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
155
TEST CONNECTION
155
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
155
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
158
PLUG
161
BRACKET TEST CONNECTIONS
164
ADAPTER FITTING TEST CONNECTION
167
FITTING TEST CONNECTIONS
170
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
173
TEST CONNECTION
200
BRACKET TEST CONNECTION
203
PLATE ON ROOF
206
SCREW PUMP TO BRACKET
206
SCREW , Replaced By: N304017006016
209
NUT , Replaced By: N913004006001
209
NUT PUMP TO BRACKET
212
FITTING AT BRACKET
215
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
