Главная
›
Mercedes
›
BUS
›
O350 TOURISMO E3 O 403-RHD EURO3
›
613.358
›
52 SHEET METAL / AIR INTAKE
›
120 AIR INTAKE IL. 1
Mercedes A6265280040 - ДЕРЖАТЕЛЬ
O350 TOURISMO E3 O 403-RHD EURO3 613.358
52 SHEET METAL / AIR INTAKE - 120 AIR INTAKE IL. 1
Поз.
Артикул
Описание
5
A6130940102
AIR CLEANERMANN + HUMMEL
6
A0030945004
FILTER ELEMENT
7
A0009901550
NUT
8
A0000943505
SEPARATOR
9
A0000941255
FASTENER
11
A0005280405
COVER AIR INTAKE PIPE
14
A0005280140
BRACKET
17
A0005280185
RUBBER MOUNTINGM10X50X20
20
N000000003275
NUT LINKAGE TO REAR AXLE M10, J 45136320070307
20
N913023010002
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
65
A0029901378
CONNECTOR
68
N000439010212
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
71
A0004291127
THRUST RING14X10X2.6MM
74
A0269970248
O-RING
77
A0000940568
MAINTENANCE INDICATOR ,950198
80
A0005280009
PLASTIC PIPE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
83
A6265280040
BRACKET AIR CLEANER TO BRACKET
