Поз.
Артикул
Описание
95
ARM FLAP NO.1
95
ARM FLAP NO.4
95
ARM FLAP NO.3
95
ARM FLAP NO.2
95
ARM FLAP NO.1
95
ARM FLAP NO.4
95
ARM FLAP NO.4
98
BALL SOCKET
101
BUSHING
104
MOUNTING SWIVEL ARM
107
WASHER BRACKET TO CAB REAR PANEL
110
NUT
110
NUT GUIDE RAIL,REAR BOTTOM
113
PIN SWIVELLING ARM ON BRACKET
116
WASHER SWIVELLING ARM ON BRACKET
119
FITTED WASHER SWIVELLING ARM ON BRACKET
120
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
122
LOCK RING , Replaced By: N000471010001
127
ARM
128
ARM
129
ARM
130
ARM
131
BUSHING
134
BRACKET
134
BRACKET
137
BRACKET
137
BRACKET
137
BRACKET
137
BRACKET
138
BRACKET , Replaced By: A6137500517
138
BRACKET
139
BRACKET
146
BRACKET
149
BRACKET
150
BRACKET
152
WASHER BRACKET TO LEFT SIDE MEMBER
155
NUT GUIDE RAIL,REAR BOTTOM
155
NUT
158
SCREW INTERMEDIATE BEARING TO BRACKET M 8X20
158
SCREW PUMP TO BRACKET
158
SCREW BRACKET TO CAB REAR PANEL M 8X20
161
WASHER COVERING TO CAB
161
WASHER EXHAUST MUFFLER TO STRAP
161
WASHER MODULATOR TO ENGINE CONTROL SHAFT
164
BRACKET LEFT,234502
164
BRACKET RIGHT,234502
165
BRACKET LEFT AND RIGHT FLAPS
166
BRACKET ,234503
167
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
167
SCREW , Replaced By: N914146006102
170
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
173
NUT BRACKET TO FLAP,234502
179
SPRING (PNEUMATIC SPRING) 700 N , GAYSAN
179
SPRING , Replaced By: A6139805364
179
SPRING (PNEUMATIC SPRING) 700 N , GAS
181
SPRING , Replaced By: A6139805464
181
SPRING , Replaced By: A6139805264
181
SPRING (PNEUMATIC SPRING) 900 N , GAS
181
SPRING (PNEUMATIC SPRING) 900 N , GAYSAN
181
SPRING (PNEUMATIC SPRING) 800 N , GAYSAN
181
SPRING (PNEUMATIC SPRING) 800 N , GAS
183
BUFFER
184
NUT CLAMP TO BRACKET
184
NUT , Replaced By: N913023006001
184
NUT SPRING-LOADED PUSH ROD
188
PANELLING IN FRONT OF REAR AXLE 715MM,222027
188
PANELLING BEHIND REAR AXLE,FRONT 715MM,222027
188
PANELLING DRIVER RELAXING ROOM 1126MM,222027
188
PANELLING PNEUMATIC SPRING,LEFT
188
PANELLING IN FRONT OF LUGGAGE COMPARTMENT FLAP
188
PANELLING BEHIND FRONT AXLE 877MM,222027
189
BRACKET PNEUMATIC SPRING,LEFT
190
BRACKET PNEUMATIC SPRING,RIGHT
191
BRACKET PNEUMATIC SPRING,RIGHT
192
SCREW CLAMP TO BRACKET M 6X14
193
NUT RETAINER USED WITH IMITATION LEATHER TRIM, 123 297291 ALSO INSTALLED ON 306113-347407 133 002318 ALSO INSTALLED ON 004116-012658
193
LOCK PROTECTIVE GRILLE
193
LOCK , Replaced By: A1269941345
193
LOCK CONDENSER TO INTERIOR PLATE,LEFT OUTSIDE
197
SHEET METAL SCREW
197
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION
197
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION 4.8X13
198
WASHER BOOT TO CAB FLOOR
198
WASHER COMPRESSED AIR LINE TO BRACKET
199
NUT , Replaced By: N913023006001
199
NUT SPRING-LOADED PUSH ROD
199
NUT CLAMP TO BRACKET
200
SCREW , Replaced By: N914146006102
200
SCREW COMPRESSED AIR LINE TO ENGINE MOUNTING SUPPORTING ARM
200
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
201
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
440
BALL PIVOT
440
BALL PIVOT , Replaced By: A6139910302
