Mercedes
›
TRUCK
›
1225 AF,1228 AF,1428 AF,1429 AF,1442 AF
›
615.266
›
24 ENGINE SUSPENSION
›
001 COOLING PARTS AND RETARDER CORROSION-PROOF IL.1
Mercedes N000125008443 - ШАЙБА
1225 AF,1228 AF,1428 AF,1429 AF,1442 AF 615.266
24 ENGINE SUSPENSION - 001 COOLING PARTS AND RETARDER CORROSION-PROOF IL.1
Поз.
Артикул
Описание
20
A6155201022
COVERING LEFT, TO BE ADAPTED DURING ASSEMBLY
20
A6525200222
COVERING LEFT
40
A6155240397
SEALING PLATE
40
A6525240097
SEALING PLATE
80
A6155201122
COVERING BOTTOM
110
A6175245240
BRACKET LEFT FRONT
150
A6155240340
BRACKET REAR LEFT
170
N000933008147
SCREW , Replaced By: N304017008021
170
N304017008021
SCREW PIPE CLAMP
180
N308676012026
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
180
N000961012122
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
180
N000125008443
WASHER EXHAUST MUFFLER TO STRAP
180
N000961012097
SCREW , Replaced By: N308676012026
180
N000125008418
WASHER , Replaced By: N000125008443
999
N913002012004
NUT END PIECE TO EXHAUST PIPE
999
A6155240497
SEALING PLATE , Replaced By: A6175241897
999
A6155240240
BRACKET LEFT FRONT, NOT USED
999
A0009941210
LOCK PROTECTIVE PLATE TO BRACKET
999
A0009842336
LOCKING PIN
