Поз.
Артикул
Описание
1
STARTING MOTOR12 V, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
2
EXCITER COILTO 002 151 64 01,002 151 69 01, 940 10/50,20/60 211713 940 12/52,22/62 008163
2
EXCITER COIL , Replaced By: A0001514755
2
EXCITER COIL , Replaced By: A0001516555
3
SCREWTO 343 151 71 01
4
CARBON BRUSH SETTO 002 151 30 01/002 151 26 01
4
CARBON BRUSH SETTO 002 151 64 01,002 151 69 01
7
SPRINGTO 002 151 30 01/002 151 26 01
8
PINION , Replaced By: A0001519613
8
PINION *** TO 002 151 64 01.002 151 69 01
8
PINIONTO 001 151 64 01,002 151 26 01
9
BUSHING DRIVE END BEARING TO 003 151 07 01,001 151 64 01
10
BUSHINGTO 004 151 58 01/003 151 87 01
10
BUSHING COMMUTATOR END TO 002 151 26 01/001 151 64 01
15
SOLENOID SWITCHTO 001 151 64 01
16
REPAIR KIT ARMATURE MOUNTING
25
ANGLE
26
SCREW , Replaced By: N304017006016
26
SCREW PUMP TO BRACKET
27
WASHER COMPRESSED AIR LINE TO BRACKET
27
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
28
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
NUT
999
SCREW , Replaced By: A0069909101
999
CONTACT RAIL , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 912 10/50,20/60 381859 912 12/52,22/62 041435 913 10/50,20/60 318135 913 12/52,22/62 008829 917 088976 919 002012 936 000214 937 016179 938 005938 939 005169 942 000051, Replaced By: A6151590120
999
GROUND CABLE , Replaced By: A6211500332
999
GROUND CABLE , Replaced By: A6151500232
999
GROUND CABLE , Replaced By: A6151500232
999
GROUND CABLE , Replaced By: A6151500232
999
NUT , Replaced By: N913017005000
999
ALTERNATOR , Replaced By: A0031546702
999
STARTING MOTOR , Replaced By: A0021516401
999
PULLEY
999
STARTING MOTOR , Replaced By: A0021516401
999
SCREWTO 004 151 58 01
999
SCREW , Replaced By: A0009909130
999
GLOW PLUG , Replaced By: A0001596001
999
GLOW PLUG , Replaced By: A0001596101
999
GLOW PLUG , Replaced By: A0001596001
999
GLOW PLUG , Replaced By: A0001596101
999
CONNECTING INSULATOR. INSULATOR , Replaced By: A0001590606
999
PULLEY
999
FAN
999
PULLEY , Replaced By: A0001557115
999
FAN , Replaced By: A0001556618
999
FAN. PULLEY , Replaced By: A0001552815
999
PULLEY
999
CARBON BRUSH SET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0001546314
999
SOLENOID SWITCH , Replaced By: A0001523710
999
BUSHING STARTER PINION
999
PINION , Replaced By: A0001518313
999
BUSHING INTERMEDIATE BEARING TO 002 151 64 01,002 151 69 01, 940 10/50,20/60 211713 940 12/52,22/62 008163
999
BUSHING , Replaced By: A0001518150
999
CARBON BRUSH SET , Replaced By: A0001515314
999
BUSHINGTO 004 151 58 01
999
SPRINGTO 002 151 64 01/002 151 65 01
999
CONTROL LEVERTO 001 151 96 01
999
SPACER ARMATURE MOUNTING TO 001 151 64 01
