Поз.
Артикул
Описание
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: "3", DELIVER ADDITIONALLY:1X 617 322 11 84,1X 344 991 72 60 UP TO IDENT NO. 5 251719
6
BUSHING
6
BUSHING
9
SHIM ,5 251719, Replaced By: A6173221184, +001A3449917260, +001N004626012135, +001N913004012007
11
SHIM BETWEEN THE SPRING LEAVES
15
SPRING BOLT
15
SPRING BOLT
19
NUT , Replaced By: N910113012005
19
HEXAGON NUT. NUT SPRING BOLT
23
CLAMP SPRING CLAMP TO SPRING LEAF NO.3
27
RIVET SPRING CLAMP TO SPRING LEAF
31
SPRING CLAMP
35
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
35
SCREW , Replaced By: N304017008027
39
NUT , Replaced By: N913004008001
39
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
40
SHIM FRONT SPRINGS TO FRONT AXLE,5 251720
41
DOWEL PIN FRONT AXLE TO FRONT SPRINGS
107
SHACKLE FRONT SPRING REAR BRACKET
107
SHACKLE FRONT-SPRING CENTRAL BRACKET VORDERACHSE II
111
BUSHING
111
BUSHING
115
SHACKLE PIN PARTS KIT
119
GREASE NIPPLE
123
GREASE NIPPLE PROTECTIVE TUBE
127
WASHER AS REQUIRED 4.00 MM
127
WASHER AS REQUIRED 4.30 MM
127
WASHER AS REQUIRED 4.20 MM
131
SEAL RING SPRING SUSPENSION
135
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
139
WASHER , Replaced By: N000125010532
139
WASHER RADIATOR TO RUBBER MOUNTING
143
NUT , Replaced By: N910113010000
143
NUT STRAP TO BRACKET
195
BEARING BRACKET TORSION BAR,FRONT,5 903513
211
PLATE FRONT SPRINGS TO FRONT AXLE
215
HELPER SPRING SPRING STOP TO FRAME BOTTOM SIDE
227
BRACKET HELPER SPRING
235
SCREW REAR EXHAUST PIPE TO MUFFLER
239
NUT STRAP TO BRACKET
239
NUT , Replaced By: N910113010000
267
U-BOLT FRONT SPRINGS TO FRONT AXLE 220 MM
267
U-BOLT FRONT SPRINGS TO FRONT AXLE 200 MM
275
NUT FRONT SPRINGS WITH TORSION BAR TO FRONT AXLE
275
NUT , Replaced By: N000934018001
999
BUSHING , Replaced By: A0003233150
999
BUSHING , Replaced By: A3523250150
