Поз.
Артикул
Описание
30
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
30
HOSE , Replaced By: A0009872827
38
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
40
BANJO UNION FROM BULKHEAD FITTING TO PRESSURE REGULATOR
60
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
60
PLASTIC PIPE RISING PIPE 4X6 MM
61
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
62
UNION NUT
64
GLAND , Replaced By: A0019901667
64
SEAL CONE
66
SLEEVE LEAK LINE
466
RESERVOIR30L,246 MM,12.5 BAR
466
RESERVOIR SERVICE BRAKE 30 L, Replaced By: A0034321801, +001A6554320073
468
BASE AIR RESERVOIR,STRAP
472
STRAP SERVICE BRAKE AIR RESERVOIR
480
SCREW END PIECE TO EXHAUST PIPE M 10X25
482
NUT STRAP TO BRACKET
482
NUT , Replaced By: N910113010000
488
LOCK (PROTECTION AGAINST TORSION),5 934167
498
FITTING AIR RESERVOIR,CONNECTION: "11"
500
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
502
SCREW PLUG , Replaced By: N000908022011
502
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
504
THRUST RING CHECK VALVE TO AIR RESERVOIR
504
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
506
O-RING CHECK VALVE TO AIR RESERVOIR
508
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
510
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
514
VALVE. DRAIN VALVE DRAIN
514
VALVE DRAIN, Replaced By: A0004322407
514
VALVE DRAIN, Replaced By: A0004322107
516
O-RING CHECK VALVE TO AIR RESERVOIR
518
THRUST RING CHECK VALVE TO AIR RESERVOIR
518
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
THRUST RING SUCTION LINE TO OIL PUMP
999
ELBOW FITTING BUTT SCREW CONNECTION "20",5 271048
999
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
999
REPAIR KITTO 000 429 26 95,KNORR
999
VALVEWABCO
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
CONNECTOR REPAIR SIZE
999
HANDLEKNORR
999
PLUG
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
PROTECTIVE CAPKNORR
999
T-FITTING LEFT AND RIGHT BRAKE HOSES
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
LOOM TIE LINE MOUNTING 280 MM
999
PRESSURE REGULATORKNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
T-FITTING LINE CONNECTION TO AIR COMPRESSOR
999
ELBOW FITTING ,5 433281
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
ELBOW FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20", Replaced By: A6209900071
999
SEAL RING LINE CONNECTION
999
SEAL RING , Replaced By: A0009870746
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
SEAL RING LINE CONNECTION
999
ADHESIVE FOIL GUIDE SIGN
999
BRACKET COMPRESSED AIR LINES
999
BRACKET ,5 171760
999
BRACKET RETURN LINE,5 537500
999
PROTECTIVE PLATE , ELIMINATED - NO LONGER REQUIRED
999
BRACKET COMPRESSED AIR LINES
999
ELBOW FITTING , Replaced By: A0039901671
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW , Replaced By: N000933008337
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: A0099900101
999
STUD BOLT BRACKET TO CYLINDER BLOCK, REAR,5 171760
999
WASHER STRAP TO SUPPORT
999
CLAMPING SLEEVEKNORR
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
T-FITTING ,5 1700795 269267, Replaced By: A0029901970
999
NUT CHECK VALVE TO AIR RESERVOIR
999
NUT SUCTION LINE TO OIL PUMP
999
SCREW PIPE CLAMP
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
UNION NUT LINE CONNECTION
999
HOLLOW SCREW HEATING CONNECTION
999
SEAL RING , Replaced By: N007603012121
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
CLAMP , Replaced By: N000000000667
