Поз.
Артикул
Описание
228
CONSOLE PEDESTAL
232
STRUT BUMPER,RIGHT
232
STRUT BUMPER,LEFT
240
SCREW APPARATUS SUPPORT TO FRAME
240
SCREW SUPPORT TO SIDE MEMBER M 14X45
240
SCREW , Replaced By: A9429901304
240
SCREW , Replaced By: N308676014012
244
NUT , Replaced By: N910113014000
244
NUT STEERING SUPPORT TO FRAME
248
BRACKET CAB,LEFT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 146509
248
MOUNTING CAB,LEFT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 146510
248
BRACKET CAB, RIGHT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 146509
248
MOUNTING CAB, RIGHT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 146510
252
MOUNTING , Replaced By: A3878908703, +001A6558902903
252
MOUNTING , Replaced By: A6208902903, +001A6558902903
252
MOUNTING , FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 146509
252
MOUNTING , FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 146510
256
WASHER TORSION BAR TO BEARING BRACKET
256
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
260
NUT COMBINATION CYLINDER TO BEARING BRACKET
260
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
264
REPAIR KIT CAB SUSPENSION,FRONT, FOR USE WITH SHORT MERCEDES-BENZ CAB5 764324
268
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
272
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
276
SCREW BRACKET TO SIDE MEMBER
280
WASHER BRACKET TO SIDE MEMBER,5 703114
284
NUT BRACKET TO SIDE MEMBER
284
NUT , Replaced By: N910113014001
288
SCREW , Replaced By: N308676014012
288
SCREW , Replaced By: A9429901304
288
SCREW APPARATUS SUPPORT TO FRAME
288
SCREW SUPPORT TO SIDE MEMBER M 14X45
292
NUT STEERING SUPPORT TO FRAME
292
NUT , Replaced By: N910113014000
296
CONSOLE CAB SUSPENSION,REAR, TO BE ADAPTED DURING ASSEMBLY
300
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
300
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
300
SCREW , Replaced By: N308676014020
304
NUT , Replaced By: N910113014001
304
NUT BRACKET TO SIDE MEMBER
308
GUIDE CAB, RIGHT
308
GUIDE CAB,LEFT
316
SCREW GUIDE TO CAB, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB
320
LOCK WASHER FITTING TO BRACKET
324
SHIM GUIDE TO CAB
328
BUSHING LATERAL GUIDE OF CAB
332
SPACER TUBE BRACKET TO CONSOLE
336
SCREW RIGHT BRACKET TO RIGHT BEARING BRACKET
340
NUT SUPPORT TO SIDE MEMBER
344
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 146509
344
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
344
SHOCK ABSORBER , Replaced By: A3878901319
344
SHOCK ABSORBER , Replaced By: A6208900119
348
JOINT , Replaced By: A0008910301
348
RUBBER MOUNTINGTO 387 890 36 19
348
RUBBER MOUNTINGTO 620 890 02 19
352
SPRING , FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 146509
352
SPRINGTO 620 890 01 19
352
SPRINGTO 620 890 00 19
352
SPRING , Replaced By: A0008910451
356
SPACER TUBE SHOCK ABSORBER MOUNTING
360
RUBBER RING SHOCK ABSORBER MOUNTING
364
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
368
WASHER SHOCK ABSORBER MOUNTING
372
NUT STRAP TO SUPPORT
376
CAP NUT VIBRATION ABSORBER
376
CAP NUT , Replaced By: N001587012010
380
SCREW , Replaced By: N304017008034
380
SCREW BRACKET TO CROSS CONNECTION STRUT
384
WASHER BRACKET TO LEFT SIDE MEMBER
384
WASHER , Replaced By: N009021008213
388
NUT , Replaced By: N913004008001
388
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
392
BRACKET VIBRATION ABSORBER TO CAB,RIGHT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 157715
392
BRACKET VIBRATION ABSORBER TO CAB,LEFT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 157715
396
BOOT VIBRATION ABSORBER, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 157715
400
SCREW END PIECE TO EXHAUST PIPE M 10X25
404
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
408
WASHER RADIATOR TO RUBBER MOUNTING
408
WASHER , Replaced By: N000125010532
412
LOCKING MECHANISM CAB LOCKING MECHANISM,LEFT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB
412
LOCKING MECHANISM CAB LOCKING MECHANISM,RIGHT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB
416
LATCH CAB LOCKING MECHANISM
420
PIN , FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB
424
LEVER
428
WASHER
432
DISC SPRING CAB LOCKING MECHANISM
436
CLAMPING SLEEVE CAB LOCKING MECHANISM
440
NUT SUPPORT TO SIDE MEMBER
444
SCREW END PIECE TO EXHAUST PIPE M 10X25
448
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
452
WASHER RADIATOR TO RUBBER MOUNTING
452
WASHER , Replaced By: N000125010532
999
BUFFERTO 620 890 02 19
999
SCREWM 16X17X28X48
999
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
999
SCREW , Replaced By: N308676012013
999
SCREW , Replaced By: A3959900501
999
SCREW , Replaced By: A0029908201
999
SCREWM 14X14X17X35
999
SCREW , Replaced By: A3169900014
999
SCREWM 14X14X22X40
999
SCREWM 14X14X18X32
999
SCREWM 14X14X27X45
999
SCREWM 16X18X18X40
999
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
999
REAR SPRING BRACKET FRONT AND REAR
999
SCREWM 12X13X18X35
999
SCREWM 12X14X13X35
999
SCREWM 14X14X24X42
999
SCREWM 14X15X15X32
999
SCREWM 14X15X21X38
999
SCREW PLATE TO SIDE MEMBER
999
SCREWM 16X17X22X42
999
SCREWM 12X13X21X38
999
SCREWM 14X15X27X44
999
SCREWM 14X15X17X34
999
SCREWM 14X15X29X46
999
SCREWM 14X15X19X36
999
SCREWM 12X13X15X32
999
SCREW , Replaced By: A0009906314
999
SCREWM 14X14X32X50
999
CROSS MEMBER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3813120015
999
SCREWM 12X13X35X52
999
SCREWM 14X15X35X52
999
SCREWM 14X15X31X48
999
SCREWM 10X11X26.5X46
999
SCREWM 12X12X10X25
999
SCREW , Replaced By: A3229903101
999
SCREW , Replaced By: N308676016020
999
SCREWM 16X16X22X40
999
SCREW , Replaced By: N000961016118
999
SCREWM 12X12X11X26
999
SCREWM 12X12X13X28
999
SCREWM 16X16X20X38
999
SCREWM 16X16X30X48
999
SCREWM 16X16X32X50
999
SCREWM 14X14X18X34
999
SCREWM 12X12X15X30
999
SCREWM 12X12X17X32
999
SCREWM 18X18X23X45
999
SCREW , Replaced By: N000961018043
999
SCREWM 16X18X63X85
999
SCREWM 16X16X20X45
999
SCREWM 12X13X13X30
999
SCREWM 12X13X23X40
999
SCREWM 16X18X26X48
999
SCREWM 12X13X12X29
999
SCREWM 16X18X38X60
999
SCREWM 12X13X25X42
999
SCREWM 16X16X38X90
999
SCREWM 14X15X18X35
999
SCREWM 16X17X24X44
999
SCREWM 12X13X63X85
999
SCREWM 12X13X58X80
999
FITTED SCREWM 10X11X14X28
999
FITTED SCREWM 10X11X24X40
999
FITTED SCREWM 18X19X57X85
999
FITTED SCREWM 10X11X25X38
999
FITTED SCREWM 18X19X25X45
999
FITTED SCREWM 18X19X38X60
999
FITTED SCREWM 18X19X33X55
999
SCREWM 16X16X24X42
999
SCREWM 18X18X33X55
999
HEXAGON HEAD BOLT , Replaced By: A0029902704
999
SCREW CONSOLE TO FRAME
999
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
NUT CONSOLE TO SUPPORT
999
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
999
NUT , Replaced By: N910113012003
999
NUT , Replaced By: N910113016001
999
NUT TORSION BAR TO BEARING BRACKET,5 904661
