Поз.
Артикул
Описание
118
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
121
FITTING (PARTS KIT),LINE RUPTURE
121
FITTING , Replaced By: A0029905971
124
SLEEVE LINE CONNECTION
127
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
127
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
129
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
130
HOLLOW SCREW HEATING CONNECTION
131
FITTING
133
PLASTIC PIPE RISING PIPE 4X6 MM
133
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
135
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
136
HOLLOW SCREW LINE CONNECTION
137
UNION NUT
137
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
137
UNION NUT LINE CONNECTIONS
139
SEAL CONE
139
GLAND BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
139
GLAND , Replaced By: A0019901667
140
SEAL RING LINE CONNECTION
140
SEAL RING LINE CONNECTION
141
SLEEVE LEAK LINE
141
BUSHING , Replaced By: N915062004000
143
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
145
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
147
FITTING LINE CONNECTION TO FIRE WALL,5 726664
149
INSULATING HOSE6 X 0.6 MM, ORDER BY THE METER
150
GASKET TRANSMISSION TO BELL HOUSING
150
GASKET , Replaced By: A3812510780
151
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
151
LINE FROM CLUTCH TO TRANSMISSION
153
BANJO UNION LINE CONNECTIONS
155
UNION NUT LINE CONNECTION
156
SCREW BRACKET TO ENGINE MOUNTING
156
SCREW , Replaced By: N308676016015
157
GLAND LINE CONNECTION
159
HOLLOW SCREW HEATING CONNECTION
160
LOCK WASHERROCKINGER TYP 59 G140,59 G150
161
SEAL RING LINE CONNECTION
163
GROMMET
165
LOOM TIE LINE MOUNTING
165
LOOM TIE LINE MOUNTING 280 MM
176
BREATHER , Replaced By: A3933280065
176
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
177
HOLLOW SCREW HEATING CONNECTION
178
TS DOUBLE FITTING SOLENOID VALVE
178
FITTING , Replaced By: A0029906071
179
SEAL RING LINE CONNECTION
180
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
185
SCREW COVER PLATE TO BRACKET
187
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
189
WASHER COMPRESSED AIR LINE TO BRACKET
189
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
191
VALVE GEAR CLUSTER SHIFT
192
CLEANERTO 000 434 22 01
193
SEAL RINGTO 000 434 23 01
194
CUP 3/2-WAY VALVE WABCO
195
HANDLETO 000 434 23 01
197
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
197
REPAIR KIT 3/2-WAY VALVE WABCO
199
NUT SUCTION LINE TO OIL PUMP
201
BRACKET AT CLUTCH PEDAL UNIT
203
SEAL RING LINE CONNECTION
205
HOLLOW SCREW HEATING CONNECTION
206
HOLLOW SCREW LINE CONNECTION
207
HOLLOW SCREW LINE CONNECTION
207
HOLLOW SCREW LINE TO OIL RADIATOR
207
HOLLOW SCREW , Replaced By: N915047012100
208
SEAL RING LINE CONNECTION
209
HOLLOW SCREW , Replaced By: N915047006100
209
HOLLOW SCREW PNEUMATIC VALVE
209
HOLLOW SCREW HEATING CONNECTION
209
HOLLOW SCREW , Replaced By: N915047006100
210
FITTING , Replaced By: A0029906071
210
FITTING , Replaced By: A0039979072
210
TS DOUBLE FITTING SOLENOID VALVE
211
SCREW (THROTTLE SCREW)
211
GOVERNOR. THROTTLE NOZZLE , Replaced By: A0002641271
212
SEAL RING LINE CONNECTION
213
SEAL RING PNEUMATIC VALVE
213
SEAL RING , Replaced By: N007603010110
214
HOLLOW SCREW 4/2-WAY VALVE
214
HOLLOW SCREW LINE CONNECTION
221
BRACKET FUEL LINE TO BELL HOUSING
221
BRACKET , Replaced By: A6454310740
223
BRACKET SENSOR CABLE TO FRONT AXLE
226
SPACER TUBE BRACKET TO CONSOLE
226
WASHER , Replaced By: A3813170553
231
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
235
SCREW CLUTCH TO FLYWHEEL
239
VALVE 4/2-WAY
239
VALVE , Replaced By: A0002601457
240
REPAIR KIT 4/2-WAY VALVE TO 000 260 14 57
240
REPAIR KIT 4/2-WAY VALVE TO 000 260 59 57
242
VALVE (SOLENOID VALVE), FOR 24-V SYSTEM,SEE SA 25498
243
REPAIR KIT SOLENOID VALVE HERION,9417237/0734/12V
243
REPAIR KIT SOLENOID VALVE HERION,9417232/0711/12V
244
BRACKET 4/2-WAY VALVE
246
SCREW TWO-WAY VALVE TO BRACKET
248
SCREW , Replaced By: N304017006026
248
SCREW CONNECTOR
248
SCREW COVER PLATE TO BRACKET
250
NUT BALL PIVOT TO LEVER
250
NUT TWO-WAY VALVE TO BRACKET
254
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
258
NUT TWO-WAY VALVE TO BRACKET
260
SCREW PIPE CLAMP
260
SCREW , Replaced By: N304017008021
262
SWITCH , Replaced By: A0015458214
262
SWITCH NEUTRAL POSITION
262
SWITCH , Replaced By: A0015455314
264
SWITCH , Replaced By: A0015451109
264
SWITCH , Replaced By: A0005459009
264
SWITCH , Replaced By: A0015452709
264
SWITCH , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 360728, Replaced By: A0005457909
264
SWITCH TORQUE REDUCER
266
SEAL RING NEUTRAL POSITION
266
SEAL RING NEUTRAL POSITION SWITCH,4 920019
268
SEAL RING NEUTRAL POSITION
270
PIN NEUTRAL POSITION
272
THREADED BUSHING NEUTRAL POSITION
274
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 1.80 MM
274
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 3.00 MM
274
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.20 MM
274
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.80 MM
274
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.60 MM
274
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 1.60 MM
274
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.00 MM
274
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.40 MM
280
LOOM TIE LINE MOUNTING
280
LOOM TIE LINE MOUNTING 280 MM
999
VALVE , Replaced By: A0004342201
999
SLEEVE , Replaced By: N915062006000
999
BANJO UNION , Replaced By: N915052006013
999
BUSHING , Replaced By: A0007630043
999
GROMMET
999
ROUND CORD RING. SEAL RING ROD END
999
REPAIR KIT SHIFT LEVER VALVE
999
HOSE , Replaced By: N040621022200
999
FITTING , Replaced By: N915059004000
999
HOSE , Replaced By: A3019971182
999
SCREW SHIFTING ROD TO TRANSMISSION
999
HANDLE (GEARSHIFT LEVER KNOB)
999
BUSHING PAWL TO ROD END,5 443047
999
SHIFTING ROD REAR
999
SHIFTING ROD
999
JOINT SHIFTING ROD TO TRANSMISSION
999
VALVE (SHIFT LEVER VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
CONNECTOR REAR SHIFTING ROD
999
HANDLE SHIFT LEVER
999
VALVE , Replaced By: A0002605057, +003A3019970682
999
BRACKET FRONT SHIFTING ROD TO REAR SHIFTING ROD
999
SHIFT LEVER REMOTE GEARSHIFT MECHANISM,4 291252
999
SHIFT LEVER REMOTE GEARSHIFT MECHANISM,4 291253
999
SHIFT LEVER
999
SHIFTING ROD SHIFTING ROD TO JOINT,4 263014-4 291252
999
SHIFTING ROD SHIFTING ROD TO JOINT,4 263014-4 291252
999
COVER PLATE AT TRANSMISSION
999
COVERING CONNECTING FLANGE
999
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
999
COVERING
999
CLAMPING PIECE SHIFTING ROD TO TRANSMISSION
999
COVER SHIFT LEVER
999
YOKE CONNECTOR
999
BUSHING SHIFT LEVER BEARING TO CAB FLOOR
999
DECALCOMANIA EIGHT-SPEED,SHIFT LEVER KNOB
999
GUMMED LABEL EIGHT-SPEED,ASHTRAY
999
DECALCOMANIA EIGHT-SPEED
999
WASHER LEVER TO BRACKET 30X10.5X4 MM
999
WASHER , Replaced By: A4039900040
999
JOINT SHIFTING ROD TO TRANSMISSION
999
BRACKET LINE MOUNTING,4 411811
999
BRACKET LINE MOUNTING,4 411811
999
BOOT SHIFTING LEVER
999
BOOT , Replaced By: A3892680097
999
BOOT , Replaced By: A3892680097
999
SHIFTING ROD , Replaced By: A6162602433
999
SHIFTING ROD , Replaced By: A6162603133
999
SHIFTING ROD REAR
999
SHIFTING ROD REAR
999
SHIFTING ROD REMOTE GEARSHIFT MECHANISM
999
SHIFTING ROD REMOTE GEARSHIFT MECHANISM
999
SHIFTING ROD REAR
999
SHIFTING ROD REAR
999
SHIFTING ROD , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 101319, Replaced By: A6172601033
999
SHIFTING ROD
999
SHIFTING ROD
999
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6172680028
999
KNOB (SHIFT LEVER HANDLE), TO BE ADAPTED DURING ASSEMBLY
999
COVER SHIFT LEVER KNOB LESS GEARSHIFT DIAGRAM
999
COVER 6-SPEED,SHIFT LEVER KNOB
999
SCREW SHOCK ABSORBER TO RAIL M 18X70
