Поз.
Артикул
Описание
9
SHIFT LEVER , ADJUST LENGTH OF SHIFTING TUBE
9
SHIFT LEVER
9
SHIFT LEVER REMOTE GEARSHIFT MECHANISM,4 291253
9
SHIFT LEVER REMOTE GEARSHIFT MECHANISM,4 291252
23
BUSHING PAWL TO ROD END,5 443047
30
BOOT SHIFTING LEVER
37
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
44
KNOB (SHIFT LEVER HANDLE), TO BE ADAPTED DURING ASSEMBLY
51
COVER 6-SPEED,SHIFT LEVER KNOB
65
BOOT , Replaced By: A6202680196
65
BOOT SHIFT LEVER BEARING
72
PIN SHIFT LEVER BEARING,K040603
79
JOINT BEARING SHIFT LEVER BEARING,K040603
79
JOINT BEARING SHIFT LEVER BEARING,K040603
79
JOINT BEARING , Replaced By: A0019813931
86
LOCK RING SHIFT LEVER BEARING
93
BRACKET SHIFT LEVER UPPER PART,K040603
100
BRACKET SHIFT LEVER LOWER PART,K040603
107
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
107
NUT , Replaced By: N913004008001
114
SCREW SUPPORT TO FENDER
114
SCREW , Replaced By: N304017008018
121
BRACKET SHIFT LEVER BEARING TO CAB FLOOR
128
RUBBER PAD SHIFT LEVER BEARING TO CAB FLOOR
135
TUBE. BUSHING CAB FLOOR COVERING
142
RUBBER PAD SHIFT LEVER TO CAB FLOOR,K040603
149
BRACKET BOOT
156
SHEET METAL SCREW BRACKET TO CAB
163
SCREW SHIFTING ROD TO SHIFT LEVER
163
SCREW , Replaced By: N000933010192
170
ROUND CORD RING. SEAL RING ROD END
177
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
184
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
191
NUT STRAP TO BRACKET
191
NUT , Replaced By: N910113010000
198
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
210
SHIFTING TUBE (TELESCOPIC TUBE)
212
SEAL RING HYDRAULIC RELEASE
219
ROD END HYDRAULIC RELEASE
226
SCREW , Replaced By: N000933010192
226
SCREW SHIFTING ROD TO SHIFT LEVER
233
ROUND CORD RING. SEAL RING ROD END
240
SPACER TUBE SHIFTING ROD TO SHIFT LEVER
247
PAWL ,5 4430475 443048, Replaced By: A6202600087, +001A6202680150
247
PAWL SHIFTING ROD,5 443048
254
BUSHING PAWL TO ROD END,5 443047
261
SPRING ROD END
268
SPRING ROD END
275
NUT STRAP TO BRACKET
275
NUT , Replaced By: N910113010000
282
SHIFTING CYLINDER HYDRAULIC RELEASE TECHNOMATIK
282
SHIFTING CYLINDER HYDRAULIC RELEASE WABCO
289
SEAL RING PISTON RINGS WABCO
296
SEAL RING SCREW FITTING WABCO
303
SEAL RING OUTSIDE WABCO
310
PIN SHIFTING CYLINDER TO PAWL 8X20 MM
310
PIN , Replaced By: N001444008235
317
PIN SHIFTING CYLINDER TO YOKE 8X45 MM
324
SPRING WASHER SHIFTING CYLINDER TO YOKE
331
WASHER BETWEEN THE SHIFTING RODS
345
SCREW FRONT SHIFTING ROD TO REAR SHIFTING ROD
352
NUT , Replaced By: N910113010000
352
NUT STRAP TO BRACKET
359
SHIFTING ROD REAR
380
CONNECTOR , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6172680028
387
SCREW CONNECTOR TO REAR SHIFTING ROD
394
JOINT SHIFTING ROD TO TRANSMISSION
394
JOINT SHIFTING ROD TO TRANSMISSION
464
SCREW SHIFTING ROD TO TRANSMISSION
478
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
485
NUT
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
BUSHING PAWL TO ROD END,5 443048
999
SHIFTING ROD REMOTE GEARSHIFT MECHANISM
999
SHIFTING ROD , Replaced By: A6162602733
999
SHIFTING ROD (TELESCOPIC SHIFTING ROD)
