Поз.
Артикул
Описание
12
SUPPORT AIR SPRING BELLOWS,RIGHT
12
SUPPORT AIR SPRING BELLOWS,LEFT
12
SUPPORT AIR SPRING BELLOWS,LEFT
12
SUPPORT AIR SPRING BELLOWS,RIGHT
14
JOINT BEARING TORSION BAR
14
JOINT BEARING TORSION BAR
18
GREASE NIPPLE
20
SCREW AIR-SPRING-BELLOWS SUPPORT TO REAR AXLE
22
SPHERICAL WASHER AIR-SPRING-BELLOWS SUPPORT TO REAR AXLE
24
NUT AIR-SPRING-BELLOWS SUPPORT TO REAR AXLE
26
PISTON PNEUMATIC SUSPENSION,K 103333
30
SEAL RING LINE CONNECTION
32
SCREW PLUG ,5 268773
34
SCREW BEARING BRACKET TO INTERMEDIATE PIECE
36
LOCK WASHERROCKINGER TYP 59 G140,59 G150
38
RUBBER BUFFER (RUBBER STOP),EMERGENCY RUNNING,K 017385
40
AIR SPRING BELLOWS FRONT AXLE PNEUMATIC SUSPENSION
40
AIR SPRING BELLOWS FRONT AXLE PNEUMATIC SUSPENSION
42
SPACER TUBE PISTON TO CONSOLE
44
NUT STEERING WHEEL TO STEERING COLUMN
46
PLATE AIR SPRING BELLOWS,TOP
48
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
50
HOLLOW SCREW , Replaced By: N915036010108
50
HOLLOW SCREW FUEL LINE TO FEED PUMP
52
SEAL RING FUEL LINE TO FEED PUMP
54
BALL PIVOT WISHBONE CONTROL ARM
56
SCREW SUPPORT TO TRANSMISSION
58
LOCK WASHER SPARE WHEEL TO BRACKET
60
BEARING BODY LEFT,5 048244
60
BEARING BODY RIGHT,5 048244
60
BEARING BODY FOR TRIANGULAR CONTROL ARM,RIGHT
60
BEARING BODY FOR TRIANGULAR CONTROL ARM,LEFT
62
SCREW CLAMP, ONE-HOLE
62
SCREW , Replaced By: N308676010017
64
NUT , Replaced By: N910113010003
64
NUT REINFORCEMENT TO BRACKET
66
SCREW REAR SPRING REAR BRACKET AND STRUT TO SIDE MEMBER
68
NUT STEERING SUPPORT TO FRAME
68
NUT , Replaced By: N910113014000
70
SCREW SUPPORTING ARM TO CYLINDER CRANKCASE M 18X60
70
SCREW , Replaced By: N308676018010
72
NUT TORSION BAR TO BEARING BRACKET,5 904661
74
CONTROL ARM , Replaced By: A6583500005
74
CONTROL ARM , Replaced By: A6583500005
74
CONTROL ARM TRIANGULAR LEMFOERDER
74
CONTROL ARM , Replaced By: A6553500305
74
CONTROL ARM , Replaced By: A6583500205
76
JOINT (CENTRAL JOINT) TO 658 350 00 05,EHRENREICH
76
JOINT (CENTRAL JOINT) TO 393 350 54 05,LEMFOERDER
76
JOINT (CENTRAL JOINT) TO 393 350 55 05,EHRENREICH
78
CONTROL ARM. REPAIR KIT , Replaced By: A0003500305
78
REPAIR KIT. JOINT WITH BALL PIVOT
78
REPAIR KIT WITH BALL PIVOT TO 393 350 55 05, 658 350 00 05 ,
78
REPAIR KIT , Replaced By: A0003500213
80
REPAIR KIT CENTRAL JOINT,WITH BALL PIVOT TO 393 350 55 05, EHRENREICH
80
REPAIR KIT CENTRAL JOINT,WITH BALL PIVOT TO 393 350 54 05, LEMFOERDER
82
SCREW CONTROL ARM TO BEARING BODY
84
SPRING WASHER , Replaced By: N000137020205
84
SPRING WASHER CONTROL ARM TO SUPPORT
88
CONTROL ARM , Replaced By: A6523500306
88
CONTROL ARM , Replaced By: A6533500106
88
CONTROL ARM REAR AXLE,BOTTOM
90
SCREW TRAILER COUPLING TO REAR CROSS MEMBER,5 734465
92
NUT CROSS MEMBER TO REINFORCEMENT
92
NUT , Replaced By: N913004020003
94
SCREW. HEXAGON HEAD BOLT BEARING BRACKET TO FRONT AXLE M20X1.5X150,5 530467
94
SCREW , Replaced By: N308765020014
96
NUT CROSS MEMBER TO REINFORCEMENT
96
NUT , Replaced By: N913004020003
98
SPACER WASHER AS REQUIRED 0.50 MM
98
SPACER WASHER AS REQUIRED 2.00 MM
98
WASHER HYDRAULIC CYLINDER TO SWIVEL ARM
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
PIN TORSION BAR TO BEARING BRACKET
999
REPAIR KIT TORSION BAR TO REAR AXLE
999
SPACER WASHER AS REQUIRED 1.00 MM
999
SPACER WASHER AS REQUIRED 4.00 MM
999
LOCK RING SHACKLE TO TORSION BAR,5 904660
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
NUT , Replaced By: N910113018004
