Поз.
Артикул
Описание
6
ACCELERATOR PEDAL , Replaced By: A6243000304
7
ACCELERATOR PEDAL (PARTS KIT), RANGE OF DELIVERY INCLUDES: 1X 655 301 00 93, 3X 000965 006077
12
SCREW ACCELERATOR PEDAL
18
BALL PIVOT LOAD SENSOR
24
NUT PUMP TO BRACKET
24
NUT , Replaced By: N913004006001
30
SHIM ACCELERATOR PEDAL
36
BOOT ACCELERATOR PEDAL
42
SCREW ACCELERATOR PEDAL TO CAB M 6X25
48
SERRATED WASHER ACCELERATOR PEDAL TO CAB, ELIMINATED,NO LONGER REQUIRED
54
SCREW ACCELERATOR PEDAL TO CAB M 6 X 20
60
SCREW VALVE TO BRACKET
60
SCREW VALVE TO BRACKET, Replaced By: N304014008002
66
NUT
72
STOP ACCELERATOR PEDAL
144
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER, 415 5 014668 416 5 000515 417 4 972023
144
ROD LOAD SENSOR CONTROL
156
BALL SOCKET PULL ROD TO LEVER
162
NUT BALL PIVOT TO LEVER
168
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
174
BEARING BRACKET ,5 181099, Replaced By: A6203000536, +002A6153010088
174
BEARING BRACKET INTERMEDIATE BEARING
186
LEVER INTERMEDIATE BEARING
186
LEVER , Replaced By: A6153000628
198
BALL PIVOT LEVER
198
BALL PIVOT , Replaced By: A3129910120
204
BALL PIVOT BOTTOM B13X5 MM
216
COVERING INTERMEDIATE BEARING
216
COVERING , Replaced By: A6153010088
222
LOCK PLATE INTERMEDIATE BEARING
228
SCREW END PIECE TO EXHAUST PIPE M 10X25
234
NUT STRAP TO BRACKET
234
NUT , Replaced By: N910113010000
240
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
252
BALL SOCKET ROD TO BALL PIVOT
258
BALL SOCKET ROD TO BALL PIVOT
264
NUT
270
SECURING CLIP. CIRCLIP
276
MANUAL CONTROL IDLING ADJUSTMENT
282
KNOB MANUAL CONTROL
282
KNOB , Replaced By: A6153020001
286
FITTED WASHER MANUAL CONTROL
286
LOCK , Replaced By: N000988030003
292
NUT MANUAL CONTROL
298
WIRE CABLE IDLING ADJUSTMENT
298
WIRE CABLE , Replaced By: A6203000130
298
WIRE CABLE , Replaced By: A6203000130
304
BRACKET
304
BRACKET , Replaced By: A3813020240
310
SCREW COVER PLATE TO COVER PLATE M 6 X 12
310
SCREW , Replaced By: N304017006018
316
COMBINATION BOLT BRACKET TO WINDOW SILL GIRDER
316
SHEET METAL SCREW , Replaced By: N914031005208
322
GROMMET WIRE CABLE THRU WINDOW SILL
328
SCREW COVER PLATE TO BRACKET
334
NUT PUMP TO BRACKET
334
NUT , Replaced By: N913004006001
340
CLAMPING PIECE WIRE CABLE TO FIRE WALL
346
CLAMPING PIECE FLEXIBLE SHAFT TO FRAME SIDE MEMBER
346
CLAMPING PIECE FLEXIBLE SHAFT TO CAB FIRE WALL
346
CLAMPING PIECE CABLE PULL TO FIRE WALL
352
SCREW CONNECTOR
358
NUT PUMP TO BRACKET
358
NUT , Replaced By: N913004006001
370
BRACKET WIRE CABLE TO RADIATOR MOUNTING CONSOLE
382
BRACKET WIRE CABLE TO FRAME SIDE MEMBER, 415 5 014669 416 5 000516 417 4 972024
388
COVER CABLE TO BRACKET
394
CLAMPING PIECE CABLE TO BRACKET
400
CLAMPING PIECE CABLE TO BRACKET
406
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
406
SCREW CAB FLOOR COVERING M 6X25
412
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
418
NUT PUMP TO BRACKET
418
NUT , Replaced By: N913004006001
424
BRACKET WIRE CABLE TO STEERING OIL TANK BRACKET, TO BE ADAPTED DURING ASSEMBLY
999
LOOM TIE LINE MOUNTING 280 MM
999
GUIDE MANUAL CONTROL
999
PAD ACCELERATOR PEDAL
999
GUIDE RAIL ACCELERATOR PEDAL TO FLOOR PLATE
999
SCREW GUIDE RAIL RETROFIT M 6X35, BORE THREADED HOLES IN CAB FLOOR TO 6.5MM
