Поз.
Артикул
Описание
6
ACCELERATOR PEDAL , Replaced By: A6243000304
6
ACCELERATOR PEDAL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6243000304
7
ACCELERATOR PEDAL (PARTS KIT), RANGE OF DELIVERY INCLUDES: 1X 655 301 00 93, 3X 000965 006077
9
SCREW ACCELERATOR PEDAL
12
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
12
SCREW CONTROL LEVER TO INJECTION PUMP LEVER
12
BALL PIVOT LOAD SENSOR
15
NUT , Replaced By: N913004006001
15
NUT PUMP TO BRACKET
18
SHIM , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 859957, Replaced By: A6153010084
18
SHIM ACCELERATOR PEDAL
21
BOOT ACCELERATOR PEDAL,4 859957
21
BOOT ACCELERATOR PEDAL
24
SCREW ACCELERATOR PEDAL TO CAB M 6X25
27
SCREW ACCELERATOR PEDAL TO CAB M 6 X 20
30
SCREW VALVE TO BRACKET
30
SCREW VALVE TO BRACKET, Replaced By: N304014008002
33
NUT
36
STOP ACCELERATOR PEDAL
72
ROD LOAD SENSOR CONTROL
72
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER, 415 5 014668 416 5 000515 417 4 972023
72
ROD , Replaced By: A3604302992
87
BEARING BRACKET INTERMEDIATE BEARING
87
BEARING BRACKET ,5 181099, Replaced By: A6203000536, +002A6153010088
87
BEARING BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 931321, Replaced By: A6203000336
93
LEVER INTERMEDIATE BEARING
93
LEVER , Replaced By: A6153000628
93
LEVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 931321, Replaced By: A3813000928
99
BALL PIVOT LEVER
99
BALL PIVOT , Replaced By: A3129910120
102
BALL PIVOT BOTTOM B13X5 MM
105
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
105
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
108
COVERING , Replaced By: A6153010088
108
COVERING INTERMEDIATE BEARING
111
LOCK PLATE INTERMEDIATE BEARING
114
SCREW END PIECE TO EXHAUST PIPE M 10X25
117
NUT , Replaced By: N910113010000
117
NUT STRAP TO BRACKET
120
PULL ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
126
BALL SOCKET ROD TO BALL PIVOT
129
BALL SOCKET ROD TO BALL PIVOT
131
NUT
134
SECURING CLIP. CIRCLIP
137
MANUAL CONTROL IDLING ADJUSTMENT
138
GUIDE MANUAL CONTROL
140
KNOB , Replaced By: A6153020001
140
KNOB MANUAL CONTROL
143
LOCK , Replaced By: N000988030003
143
FITTED WASHER MANUAL CONTROL
146
NUT MANUAL CONTROL
149
WIRE CABLE IDLING ADJUSTMENT
149
WIRE CABLE IDLING ADJUSTMENT
152
BRACKET IDLING ADJUSTER,4 821622
152
BRACKET , Replaced By: A3813020240
152
BRACKET
155
SCREW , Replaced By: N304017006018
155
SCREW COVER PLATE TO COVER PLATE M 6 X 12
155
SCREW COVER PLATE TO BRACKET
158
SHEET METAL SCREW , Replaced By: N914031005208
158
COMBINATION BOLT BRACKET TO WINDOW SILL GIRDER
159
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
159
WASHER COMPRESSED AIR LINE TO BRACKET
160
NUT , Replaced By: N913004006001
160
NUT PUMP TO BRACKET
161
GROMMET
161
GROMMET WIRE CABLE THRU WINDOW SILL
164
BRACKET WIRE CABLE,4 870323
166
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
168
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
171
NUT BALL PIVOT TO LEVER
176
CLAMP , Replaced By: A6739950001
176
CLAMP DELIVERY AND SUCTION LINES TO STEERING
179
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
180
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
182
NUT BALL PIVOT TO LEVER
189
CLAMPING PIECE WIRE CABLE TO FIRE WALL
189
CLAMPING PIECE FLEXIBLE SHAFT TO CAB FIRE WALL
196
CLAMPING PIECE CABLE PULL TO FIRE WALL
196
CLAMPING PIECE FLEXIBLE SHAFT TO FRAME SIDE MEMBER
203
SCREW CONNECTOR
211
NUT , Replaced By: N913004006001
211
NUT PUMP TO BRACKET
225
BRACKET WIRE CABLE TO RADIATOR MOUNTING CONSOLE
239
COVER CABLE TO BRACKET
246
CLAMPING PIECE CABLE TO BRACKET
260
SCREW CAB FLOOR COVERING M 6X25
274
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
274
WASHER COMPRESSED AIR LINE TO BRACKET
999
PAD ACCELERATOR PEDAL
999
GUIDE RAIL ACCELERATOR PEDAL TO FLOOR PLATE
999
SCREW GUIDE RAIL RETROFIT M 6X35, BORE THREADED HOLES IN CAB FLOOR TO 6.5MM
