Поз.
Артикул
Описание
4
RELAY , Replaced By: A0035459605
4
RELAYA33
4
RELAYA33, Replaced By: A0009822123
4
RELAY , Replaced By: A0035459605
4
RELAY REAR FOGLAMP
4
RELAY REAR FOGLAMP
8
DIODE CASE AUXILIARY HEATER
12
DIODE BOX RELAY TYP: AK 336.1
12
CASE , Replaced By: A0005400024
13
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
13
SHEET METAL SCREW BRACKET TO FLOOR PLATE
14
SWITCH MICRO-SWITCH
16
SCREW SWITCH TO MOUNTING PLATE
18
NUT BRACKET MOUNTING
18
NUT , Replaced By: N304032003001
20
WASHER MICRO-SWITCH
24
SCREW STEP SWITCH AM 5X10
28
NUT TWO-WAY VALVE TO BRACKET
34
SWITCH ADDITIONAL FLOODLIGHT,5 216258
34
SWITCH WEBASTO HEATER, IN CENTRAL ELECTRICAL COMPARTMENT
38
LENS WEBASTO HEATER
42
CAP REAR FOGLAMP SWITCH
46
BULB TELL-TALE LAMP
46
BULB2W
50
WASHER PUSHBUTTON SWITCH
50
WASHER PUSHBUTTON SWITCH
58
FUSEA16
62
LOOM TIE LINE MOUNTING 280 MM
66
CLIP CABLE HARNESS TO ROOF RAIL
70
PIN BUSHING HOUSING UNIPOLAR
74
PLUG HOUSING 3-POLE
78
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
82
PLUG HOUSING 8-POLE
86
ELECTRIC CABLE FROM FRONT PLUG CONNECTION TO FUEL PUMP,4 495587
90
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
94
PIN BUSHING HOUSING BIPOLAR
98
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
98
PIN BUSHING , Replaced By: A0075458226
98
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
102
GROMMET
106
PIN BUSHING HOUSING 4-POLE
110
FITTING
116
ELECTRIC CABLE CAB, BRANCH-OFFS TO FUSE BOXES,RELAYS NOS.1-4,DIODES NOS.1-2,4 495587
116
CABLE HARNESS , Replaced By: A3835401136
116
ELECTRIC CABLE CAB, BRANCH-OFFS TO FUSE BOXES,RELAYS NOS.1-5,DIODES NOS.1-5,TEST CONNECTION,4 495588 TO BE ADAPTED DURING ASSEMBLY
116
ELECTRIC CABLE , Replaced By: A3835400936
116
ELECTRIC CABLE CAB, BRANCH-OFFS TO FUSE BOXES,RELAYS NOS.1-5,DIODES NOS.1-5,TEST CONNECTION, EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 495598-5 003998 TO BE ADAPTED DURING ASSEMBLY
116
ELECTRIC CABLE CAB, BRANCH-OFFS TO FUSE BOXES,RELAYS NOS.1-5,DIODES NOS.1-5,TEST CONNECTION,4 495588 TO BE ADAPTED DURING ASSEMBLY
116
CABLE HARNESS , Replaced By: A3835401236
116
ELECTRIC CABLE CAB,BRANCH-OFFS TO FUSE BOXES,RELAYS NOS.1-2,CONTROL UNIT,4 495588
116
ELECTRIC CABLE , Replaced By: A3835401036
116
CABLE HARNESS , Replaced By: A3835401336
116
ELECTRIC CABLE CAB, BRANCH-OFFS TO FUSE BOXES,RELAYS NOS.1-4,DIODES NOS.1+2,TEST CONNECTION,4 495588 TO BE ADAPTED DURING ASSEMBLY
116
ELECTRIC CABLE , Replaced By: A3835400836
116
ELECTRIC CABLE CAB
124
PIN BUSHING HOUSING UNIPOLAR
128
PIN BUSHING HOUSING UNIPOLAR
132
PIN BUSHING HOUSING BIPOLAR
136
PIN BUSHING HOUSING 3-POLE
140
PIN BUSHING HOUSING 6-POLE
148
PIN BUSHING HOUSING 8-POLE
152
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
156
PIN BUSHING HOUSING 5-POLE
160
PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 4-6 MM2
160
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
160
PIN BUSHING , Replaced By: A0075458226
160
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
168
PIN BUSHING HOUSING PIN BUSHING 5.3 MM
168
BOOT PIN BUSHING
172
GROMMET3.0 MM
192
LOOM TIE LINE MOUNTING
192
LOOM TIE LINE MOUNTING 280 MM
194
PIN BUSHING HOUSING UNIPOLAR
