Поз.
Артикул
Описание
7
ACCELERATOR PEDAL (PARTS KIT), RANGE OF DELIVERY INCLUDES: 1X 655 301 00 93, 3X 000965 006077
12
SCREW ACCELERATOR PEDAL
18
BALL PIVOT LOAD SENSOR
24
NUT PUMP TO BRACKET
24
NUT , Replaced By: N913004006001
30
SHIM ACCELERATOR PEDAL
36
BOOT ACCELERATOR PEDAL
42
SCREW ACCELERATOR PEDAL TO CAB M 6X25
48
SCREW ACCELERATOR PEDAL TO CAB M 6X20
54
SERRATED WASHER ACCELERATOR PEDAL TO CAB, ELIMINATED,NO LONGER REQUIRED
60
SCREW VALVE TO BRACKET
60
SCREW VALVE TO BRACKET, Replaced By: N304014008002
66
NUT
72
STOP ACCELERATOR PEDAL
144
ROD LOAD SENSOR CONTROL
144
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER, 415 5 014668 416 5 000515 417 4 972023
156
BALL SOCKET PULL ROD TO LEVER
162
NUT BALL PIVOT TO LEVER
168
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
174
BEARING BRACKET INTERMEDIATE BEARING
174
BEARING BRACKET ,5 181099, Replaced By: A6203000536, +002A6153010088
186
LEVER INTERMEDIATE BEARING
186
LEVER , Replaced By: A6153000628
198
BALL STUD. BALL PIVOT TOP B10X4,5 MM
204
BALL PIVOT BOTTOM B13X5 MM
216
COVERING INTERMEDIATE BEARING
216
COVERING , Replaced By: A6153010088
222
LOCK PLATE INTERMEDIATE BEARING
228
SCREW END PIECE TO EXHAUST PIPE M 10X25
234
NUT STRAP TO BRACKET
234
NUT , Replaced By: N910113010000
240
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
252
BALL SOCKET ROD TO BALL PIVOT
258
BALL SOCKET ROD TO BALL PIVOT
264
NUT
270
SECURING CLIP. CIRCLIP
276
MANUAL CONTROL IDLING ADJUSTMENT
279
GUIDE MANUAL CONTROL
282
KNOB MANUAL CONTROL
282
KNOB , Replaced By: A6153020001
288
FITTED WASHER MANUAL CONTROL
288
LOCK , Replaced By: N000988030003
294
NUT MANUAL CONTROL
300
WIRE CABLE IDLING ADJUSTMENT
300
WIRE CABLE , Replaced By: A6203000130
306
BRACKET
306
BRACKET , Replaced By: A3813020240
312
SCREW COVER PLATE TO COVER PLATE M 6 X 12
312
SCREW , Replaced By: N304017006018
318
COMBINATION BOLT BRACKET TO WINDOW SILL GIRDER
318
SHEET METAL SCREW , Replaced By: N914031005208
322
WASHER COMPRESSED AIR LINE TO BRACKET
322
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
330
SCREW COVER PLATE TO BRACKET
336
NUT PUMP TO BRACKET
336
NUT , Replaced By: N913004006001
338
GROMMET WIRE CABLE THRU WINDOW SILL
342
CLAMPING PIECE WIRE CABLE TO FIRE WALL
348
CLAMPING PIECE FLEXIBLE SHAFT TO FRAME SIDE MEMBER
348
CLAMPING PIECE CABLE PULL TO FIRE WALL
348
CLAMPING PIECE FLEXIBLE SHAFT TO CAB FIRE WALL
366
SCREW CONNECTOR
372
NUT PUMP TO BRACKET
372
NUT , Replaced By: N913004006001
384
BRACKET WIRE CABLE TO STEERING OIL TANK BRACKET, TO BE ADAPTED DURING ASSEMBLY
390
LOOM TIE LINE MOUNTING 280 MM
396
BRACKET CABLE TO RADIATOR MOUNTING
402
BRACKET WIRE CABLE TO FRAME SIDE MEMBER, 415 5 014669 416 5 000516 417 4 972024
408
COVER CABLE TO BRACKET
414
CLAMPING PIECE CABLE TO BRACKET
420
CLAMPING PIECE CABLE TO BRACKET
426
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
426
SCREW CAB FLOOR COVERING M 6X25
432
WASHER COMPRESSED AIR LINE TO BRACKET
432
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
438
NUT PUMP TO BRACKET
438
NUT , Replaced By: N913004006001
999
PAD ACCELERATOR PEDAL
999
ACCELERATOR PEDAL , Replaced By: A6243000304
999
GUIDE RAIL ACCELERATOR PEDAL TO FLOOR PLATE
999
SCREW GUIDE RAIL RETROFIT M 6X35, BORE THREADED HOLES IN CAB FLOOR TO 6.5MM
