Поз.
Артикул
Описание
116
BRACKET PARTITION-PANEL-TO-COMPRESSOR REFRIGERANT LINE TO WHEELHOUSE
122
HEXAGON HEAD BOLT
122
SCREW , Replaced By: N910105006002
128
NUT , Replaced By: N913019006000
128
NUT , Replaced By: N913012006001
128
NUT CLAMP TO BRACKET
134
BUSHING MOTOR TO BRACKET
140
GROMMET BREATHER LINE
146
SCREW OIL LINE TO CRANKCASE
152
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
158
WASHER COMPRESSED AIR LINE TO BRACKET
158
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
164
NUT , Replaced By: N913023006001
164
NUT , Replaced By: N910112006001
164
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
272
SUCTION LINE
272
SUCTION LINE
272
SUCTION LINE , Replaced By: A0001300457
272
SUCTION LINE , Replaced By: A0001300557
278
SUCTION LINE , Replaced By: A6171301557
278
SUCTION LINE
284
VALVE INSERT , NOT USED
290
CAP (PARTS KIT),CAP
290
SEAL , Replaced By: A1238320033
290
SEAL RING , Replaced By: A1238320033
290
CAP , Replaced By: A2019880635
296
SUCTION LINE , Replaced By: A0001300657
296
SUCTION LINE , 617.912 10/50,20/60 138591 617.912 12/52,22/62 126949 615.940 10/50,20/60 273005 615.940 12/52,22/62 010548 616.912 10/50,20/60 240101 616.912 12/52,22/62 062232
302
VALVE INSERT , NOT USED
308
CAP (PARTS KIT),CAP
308
SEAL , Replaced By: A1238320033
308
SEAL RING , Replaced By: A1238320033
308
CAP , Replaced By: A2019880635
314
SEAL RING , Replaced By: A1249970345
314
SEAL RING , Replaced By: A1409970945
314
O-RING HOSE TO EXPANSION VALVE 17X2
332
SCREW BRACKET TO SIDE MEMBER
332
SCREW , Replaced By: N304017010002
338
SCREW REAR AXLE REGULATING SOLENOID VALVE M 8X95
344
NUT
350
WASHER
350
WASHER , Replaced By: A3129901940
356
COMBINATION BOLT
362
NUT BATTERY MOUNTING
362
NUT CYLINDER TO BRACKET TO0002902112
368
SCREW , Replaced By: N304017006034
368
SCREW COVER PLATE TO COVER PLATE M 6 X 10
374
WASHER COMPRESSED AIR LINE TO BRACKET
374
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
380
SPRING WASHER , Replaced By: N000137008212
380
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
398
BRACKET CYLINDER HEAD,FRONT, 615.940 10/50,20/60 273005 615.940 12/52,22/62 010548 616.912 10/50,20/60 240101 616.912 12/52,22/62 062232
404
CLAMP REFRIGERANT LINE TO BRACKET, 615.940 10/50,20/60 273005 615.940 12/52,22/62 010548 616.912 10/50,20/60 240101 616.912 12/52,22/62 062232
410
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
410
SCREW , Replaced By: N304017008039
416
SCREW COVER PLATE TO BRACKET
416
SCREW PUMP TO BRACKET
422
WASHER BRACKET TO HEAT SHIELD
428
CLAMP LINES TO BRACKET, 031425 900891
999
GASKET KIT BETWEEN CONNECTION AND REFRIGERANT LINE TO 000 230 47 11
999
BRACKET SELF-LEVELLING DEVICE LINE AND REFRIGERANT LINE TO THERMOSTAT HOUSING, 912 10/59,20/60 073576 912 12/52,22/62 067786 912:ONLY FOR CHASSIS 123.105,132,190
999
FILTER BOWL , /30 FROM ENGINE: 615.940 10/50,20/60 026061 615.940 12/52,22/62 001122 615.941 10/50,20/60 011372 615.941 12/52,22/62 001498
999
BRACKET .
999
NUT , Replaced By: N308673012002
999
SCREW ,5 903514, Replaced By: N000960012353
