Поз.
Артикул
Описание
66
TANK CAB,FRONT,5 129373
70
RADIATOR CAP
76
DRAIN PIPE EXPANSION TANK
76
DRAIN PIPE
79
HOSE
79
HOSE , Replaced By: A0219977682
79
HOSE OVERFLOW
79
HOSE OVERFLOW
79
HOSE , Replaced By: A0139978682
93
BRACKET EXPANSION TANK,LEFT
96
BRACKET EXPANSION TANK,RIGHT
108
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
111
WASHER COMPRESSED AIR LINE TO BRACKET
111
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
117
STRAP EXPANSION TANK,LEFT
120
STRAP EXPANSION TANK,RIGHT
129
SHIM EXPANSION TANK,LEFT
132
SHIM EXPANSION TANK,RIGHT
138
SCREW CLAMP MOUNTING M 6X16
138
SCREW , Replaced By: N000000001146
144
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
150
WASHER COMPRESSED AIR LINE TO BRACKET
150
WASHER , Replaced By: N009021006208
482
BREATHER PIPE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
485
CLIP CABLE HARNESS TO ROOF RAIL
497
BRACKET DE-AERATION LINE TO CAB
500
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
503
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
503
CLAMP ,K 147121, Replaced By: N000000000319
503
CLAMP , Replaced By: N916016008200
503
CLAMP , Replaced By: A3604300143
506
SCREW CLAMP MOUNTING M 6X16
506
SCREW , Replaced By: N000000001146
509
NUT PUMP TO BRACKET
509
NUT , Replaced By: N913004006001
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
HOSE , Replaced By: A0149975782
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
999
BRACKET , Replaced By: A3875011420
999
BRACKET OIL DIPSTICK TO RADIATOR
999
SCREW EXHAUST PIPE TO BRACKET
999
LINE (HEATING LINE),FROM ENGINE TO HEATER
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
999
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR
999
BRACKET HEATING PIPE
999
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: N000933008337
999
SCREW , Replaced By: N304017008018
999
SCREW , Replaced By: A4609900601
999
SCREW , Replaced By: A0099900101
999
SEAL RING FUEL LINE TO FEED PUMP
999
SCREW PLUG WATER DRAIN
999
SCREW SUPPORT TO FENDER
999
NUT STRAP TO BRACKET
999
GASKET HEATING PIPE TO ENGINE
