Поз.
Артикул
Описание
222
CONSOLE CAB SUSPENSION,REAR
230
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
230
SCREW , Replaced By: N308676014020
230
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
230
SCREW , Replaced By: N308676014020
232
NUT BRACKET TO SIDE MEMBER
232
NUT , Replaced By: N910113014001
232
NUT , Replaced By: N910113014001
248
BASE CAB SUSPENSION,REAR,5 073120
250
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
250
SCREW , Replaced By: N308676014020
252
STRUT , Replaced By: A6558910224, +002A6558910118
252
STRUT CAB MOUNTING,REAR (LEAF SPRING SUSPENSION)
254
SHIM STRUT TO CONSOLE
256
SCREW CONSOLE TO SIDE MEMBER
256
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
256
SCREW , Replaced By: N308676012012
256
SCREW , Replaced By: N308676012012
258
LOCK WASHER FITTING TO BRACKET
259
WASHER
260
SPRING (LEAF SPRING),CAB SUSPENSION
260
SPRING (LEAF SPRING),CAB SUSPENSION
262
BUSHING LEAF SPRING
264
TUBE LEAF SPRING, TO BE ADAPTED DURING ASSEMBLY
264
TUBE , Replaced By: A3638910218
266
WASHER LEAF SPRING TO STRUT, DISCONTINUED,PART IS NO LONGER REQUIRED
268
SCREW LEAF SPRING TO STRUT
268
SCREW SPRING TO STRUT, MODEL 416,417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB5 215244
268
SCREW LEAF SPRING TO STRUT
270
WASHER LEAF SPRING TO STRUT
272
NUT SUPPORT TO SIDE MEMBER
274
WASHER RADIATOR TO RUBBER MOUNTING
274
WASHER , Replaced By: N000125010532
276
RAIL (CONNECTING RAIL), DELIVER ADDITONALLY:1X 000960 018040 UP TO IDENT NO. 5 101988
276
RAIL , Replaced By: A6558900922
276
RAIL CAB SUSPENSION,REAR
276
RAIL , Replaced By: A6558900122
276
RAIL (CONNECTING RAIL)
276
RAIL , Replaced By: A6558900722
276
RAIL CAB SUSPENSION,REAR
276
RAIL , Replaced By: A6558900622
276
RAIL , Replaced By: A6558900322
276
RAIL (CONNECTING RAIL)
276
RAIL , Replaced By: A6558900522
276
RAIL CAB SUSPENSION,REAR
280
CYLINDRICAL PIN
282
BUFFER RAIL STOP
284
MOUNTING CAB SUSPENSION,REAR
286
MOUNTING CAB SUSPENSION,REAR
286
MOUNTING CAB SUSPENSION,REAR
286
MOUNTING CAB SUSPENSION,REAR
286
MOUNTING , Replaced By: A3878910072
286
MOUNTING , Replaced By: A3878910072
286
MOUNTING , Replaced By: A3878910072
288
SCREW BUFFER AND MOUNTING TO RAIL M 8X20
290
SCREW PIPE CLAMP
290
SCREW , Replaced By: N304017008021
290
SCREW , Replaced By: N304017008021
292
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
294
WASHER EXHAUST MUFFLER TO STRAP
294
WASHER , Replaced By: N000125008443
294
WASHER BRACKET TO CROSS MEMBER
294
WASHER BUFFER AND MOUNTING TO RAIL
296
MOUNTING CAB LOCKING MECHANISM
296
MOUNTING CAB LOCKING MECHANISM
296
MOUNTING CAB MOUNTING,REAR,4 972621
296
MOUNTING CAB MOUNTING,REAR,4 972621
296
MOUNTING CAB LOCKING MECHANISM
298
PIN BEARING BRACKET,4 972621
298
PIN BEARING BRACKET,4 972621
300
SPACER TUBE BEARING BRACKET
300
SPACER TUBE BEARING BRACKET
300
SPACER TUBE BEARING BRACKET
302
LOCK RING BEARING BRACKET,4 972621
304
SCREW , Replaced By: N000960016251
304
SCREW , Replaced By: N000960016251
304
SCREW SPACER TUBE TO MOUNTING
304
SCREW SPACER TUBE TO MOUNTING
306
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
306
NUT COMBINATION CYLINDER TO BEARING BRACKET
308
PLATE MOUNTING AND RAIL TO LEAF SPRING
310
BASE MOUNTING AND RAIL TO LEAF SPRING
312
SCREW MOUNTING AND RAIL TO LEAF SPRING
312
SCREW STRAP TO BRACKET
314
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
324
SCREW , Replaced By: N000960018142
324
SCREW SHOCK ABSORBER TO RAIL
324
SCREW SHOCK ABSORBER TO RAIL
330
NUT , Replaced By: N910113018004
330
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
332
SPACER TUBE , Replaced By: A3878910453
332
SPACER TUBE VIBRATION ABSORBER TO CONSOLE
336
SPACER TUBE SHOCK ABSORBER TO RAIL
336
SPACER TUBE SHOCK ABSORBER TO RAIL
336
SPACER TUBE VIBRATION ABSORBER TO CONSOLE
338
SPACER TUBE MOUNTING TO CONSOLE
338
SPACER TUBE MOUNTING TO CONSOLE
338
SPACER TUBE SHOCK ABSORBER TO RAIL
340
SCREW , Replaced By: N000960018072
340
SCREW VIBRATION ABSORBER TO CONSOLE
350
FASTENER (CENTRAL LOCK) CAB LOCKING MECHANISM
350
FASTENER , Replaced By: A0008902389
350
FASTENER , Replaced By: A0008902389
352
ROD CENTRAL LOCK
352
ROD CENTRAL LOCK,5 002668
352
ROD CENTRAL LOCK
354
PIN PULL TO FASTENER, MODEL 416,417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB DISCONTINUED,PART IS NO LONGER REQUIRED
356
WASHER BRACKET TO CROSS MEMBER
358
LOCK , Replaced By: N912002008003
358
LOCK , Replaced By: N912002008003
358
LOCK PULL TO FASTENER
360
CONSOLE CENTRAL LOCK
362
SCREW CENTRAL LOCK TO CAB M 10X16
362
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
362
SCREW CENTRAL LOCK TO CAB M 10X16
364
SCREW END PIECE TO EXHAUST PIPE M 10X25
366
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
368
NUT , Replaced By: N910113010000
368
NUT , Replaced By: N910113010000
368
NUT STRAP TO BRACKET
370
WASHER , Replaced By: N000125010532
370
WASHER , Replaced By: N000125010532
370
WASHER RADIATOR TO RUBBER MOUNTING
372
BRACKET ROD THRU CAB
374
SEAL ROD THRU CAB
376
CLAMPING SLEEVE ROD TO BRACKET
378
LEVER CAB LOCKING MECHANISM
378
LEVER CAB LOCKING MECHANISM,5 132082
378
LEVER CAB LOCKING MECHANISM
378
LEVER CAB LOCKING MECHANISM,5 002668
378
LEVER CAB LOCKING MECHANISM,5 002668
378
LEVER CAB LOCKING MECHANISM,5 002668
378
LEVER CAB LOCKING MECHANISM
378
LEVER CAB LOCKING MECHANISM
380
BUSHING LEVER TO CAB
382
HANDLE CAB LOCKING MECHANISM
384
SCREW BUSHING AND LEVER TO CAB
386
NUT , Replaced By: N913004008001
386
NUT , Replaced By: N913004008001
386
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
387
RIVET BUSHING AND LEVER TO CAB
388
CLAMPING SLEEVE , Replaced By: N001481005039
388
CLAMPING SLEEVE , Replaced By: N001481005039
388
CLAMPING SLEEVE , Replaced By: N001481005039
388
CLAMPING SLEEVE LEVER MOUNTING
388
CLAMPING SLEEVE LEVER MOUNTING
390
WASHER , Replaced By: N000125015019
390
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
392
RETAINING RING LEVER MOUNTING, MODEL 416,417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB5 287988
392
RETAINING RING LEVER MOUNTING, MODEL 416,417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB5 287988
394
WASHER BRACKET TO CROSS MEMBER
396
PIN LEVER TO ROD
398
COTTER PIN PULL ROD TO LEVER
412
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X38
420
SCREW , Replaced By: N308676014020
420
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
420
SCREW RUBBER MOUNTING TO SUPPORTING ARM M 16X1.5X38
422
BUFFER (HOLLOW RUBBER SPRING),CAB
422
RUBBER BUFFER CAB
424
FLANGE HOLLOW RUBBER SPRING
426
BUSHING HOLLOW RUBBER SPRING
426
SPACER TUBE HOLLOW RUBBER SPRING,5 956658
428
WASHER , Replaced By: A4432610076
428
WASHER HOLLOW RUBBER SPRING TO CAB,5 956657
428
WASHER , Replaced By: A6558910210
428
WASHER HOLLOW RUBBER SPRING
430
SCREW EXHAUST PIPE TO BRACKET
430
SCREW , Replaced By: N304017010051
430
SCREW
432
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
435
RUBBER BUFFER CAB
999
PUMP , Replaced By: A0005536501
999
PUMP (HAND PUMP) POWER PACKER,4 733732
999
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
999
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
999
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING POWER PACKER
999
PIN PULL TO FASTENER
999
WASHER BRACKET TO SIDE MEMBER,5 703114
999
MOUNTING (RUBBER BUFFER)
999
WASHER LEFT AND RIGHT CONSOLES TO CAB
999
BUSHING SPRING
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
GUMMED LABEL CAB LOCKING MECHANISM
999
REPAIR KIT CAB SUSPENSION,FRONT
999
WASHER BEARING BRACKET
999
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
BRACKET LEFT FENDER
999
BRACKET RIGHT FENDER
999
GUIDE SIGN DANGER AREA IN FRONT OF TILTED CAB
999
REPAIR KIT , Replaced By: A3879920003, +002A6208910017, +001A3638910023
999
RAIL , Replaced By: A3878901222
999
LEVER CAB SUSPENSION
999
LEVER , NO LONGER AVAILABLE,ORDER INDIVIDUAL PARTS
999
LEVER , NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
LEVER
999
SHACKLE
999
SHACKLE
999
SPACER TUBE MOUNTING TO CONSOLE
999
SHIM MOUNTING TO CONSOLE
