Поз.
Артикул
Описание
6
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
6
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
12
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
18
FITTING (PARTS KIT),LINE RUPTURE
24
VALVE ,K 169122
24
VALVE ,K 169122
30
BOOT CHECK VALVE,K 169122
36
CLAMP CHECK VALVE,K 169122
36
CLAMP LINE MOUNTING
36
CLAMP , Replaced By: N000000000665
36
CLAMP LINE CONNECTION
36
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
42
HOLLOW SCREW FUEL LINE TO FEED PUMP
42
HOLLOW SCREW , Replaced By: N915036010108
42
HOLLOW SCREW HEATING CONNECTION
48
SEAL RING FUEL LINE TO FEED PUMP
48
SEAL RINGTO 000 553 03 05,000 553 18 05,
54
GROMMET FUEL LINE THRU FRAME SIDE MEMBER,5 406237
54
GROMMET LINE MOUNTING 50/45 MM
54
GROMMET FUEL LINE THRU FRAME SIDE MEMBER 38/30 MM
54
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
54
GROMMET42/36 MM, NOT USED
78
LOOM TIE LINE MOUNTING
78
LOOM TIE LINE MOUNTING 280 MM
