Поз.
Артикул
Описание
5
SCREW BRACKET TO SIDE MEMBER
7
NUT BRACKET TO SIDE MEMBER
7
NUT , Replaced By: N910113014001
9
RIVET FRAME TRUSS TO SIDE MEMBER
12
FUEL TANK , Replaced By: A3874701001
12
FUEL TANK
15
FILLER CAP , Replaced By: A0004717930
15
FILLER CAP , Replaced By: A0004700305
15
FILLER CAP , Replaced By: A0004700305
15
FILLER CAP , Replaced By: A0004700305
15
FILLER CAP
16
SEAL RING
18
CHAIN FILLER CAP
21
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
24
SENDER UNIT , EXHAUST STOCK OF OLD PART NUMBER FIRST UP TO CHASSIS 4 656938, Replaced By: A0055423917
24
SENDER UNIT , Replaced By: A0085428117
24
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426517, +001A0005409917
24
SENDER UNIT , Replaced By: A0085428317
24
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426317, +001A0005409917
24
SENDER UNIT FUEL GAUGE,K 169123
24
SENDER UNIT , Replaced By: A0045423817, +001A3054760126, +002A3879900078
24
SENDER UNIT ,4 316249, Replaced By: A0045423817, +001A3054760126, +002A3879900078
24
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426517, +001A0005409917
28
EXPANSION PLUG
31
CONNECTOR RIGHT,177-LITER
31
SLEEVE , Replaced By: N915062008000
31
SLEEVE FEED
34
FILLER CAP IN PLACE OF FUEL GAUGE SENDER UNIT
37
RIVET FRAME TRUSS TO SIDE MEMBER
37
RIVET FRAME TRUSS TO SIDE MEMBER
46
CONSOLE REAR EXHAUST PIPE TO CONSOLE
49
SUPPORT FUEL TANK TO FRAME
49
SUPPORT FUEL TANK TO FRAME
49
SUPPORT FUEL TANK,5 150326
49
SUPPORT FUEL TANK TO FRAME
49
SUPPORT FUEL TANK
49
SUPPORT , Replaced By: A6174703742
49
SUPPORT FUEL TANK TO FRAME
49
SUPPORT , Replaced By: A6174703742
49
SUPPORT FUEL TANK TO FRAME
49
SUPPORT FUEL TANK,5 150326
49
SUPPORT FUEL TANK,5 150326
49
SUPPORT , Replaced By: A6234700542
49
SUPPORT FUEL TANK,5 150326
49
SUPPORT FUEL TANK TO FRAME
49
SUPPORT , Replaced By: A6234700542
49
SUPPORT , Replaced By: A6174703742
49
SUPPORT , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6214700142
49
SUPPORT FUEL TANK TO FRAME
52
SUPPORT FUEL TANK TO FRAME
52
SUPPORT , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3954700742
52
SUPPORT , Replaced By: A6564701042
52
SUPPORT FUEL TANK
52
SUPPORT FUEL TANK
52
SUPPORT FUEL TANK
52
SUPPORT FUEL TANK TO FRAME, TO BE ADAPTED DURING ASSEMBLY
52
SUPPORT FUEL TANK
52
SUPPORT FUEL TANK
52
SUPPORT FUEL TANK TO FRAME
56
SCREW BRACKET TO CAB CONSOLE,K 035197
56
SCREW BRACKET TO SIDE MEMBER
56
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
56
SCREW , Replaced By: N308676014020
56
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
56
SCREW AT CROSS MEMBER
56
SCREW BRACKET TO CAB CONSOLE,K 035197
56
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
56
SCREW CONSOLE TO RIGHT SIDE MEMBER M 14X55
56
SCREW AT CROSS MEMBER
56
SCREW BRACKET TO SIDE MEMBER
58
NUT , Replaced By: N910113014001
58
NUT BRACKET TO SIDE MEMBER
62
BASE SUPPORT TO SIDE MEMBER
68
REINFORCEMENT REINFORCEMENT RAIL TO CONSOLE
68
REINFORCEMENT REINFORCEMENT RAIL TO CONSOLE,750 MM
68
REINFORCEMENT REINFORCEMENT RAIL TO CONSOLE
68
REINFORCEMENT REINFORCEMENT RAIL TO CONSOLE,750 MM
68
REINFORCEMENT REINFORCEMENT RAIL TO CONSOLE
68
REINFORCEMENT REINFORCEMENT RAIL TO CONSOLE
68
REINFORCEMENT REINFORCEMENT RAIL TO CONSOLE,750 MM
77
SCREW CONSOLE TO SIDE MEMBER
80
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
80
WASHER , Replaced By: N000125015019
80
WASHER
83
NUT SUPPORT TO SIDE MEMBER
86
STRAP FUEL TANK TO SUPPORT
89
PIN STRAP TO SUPPORT
92
NUT STRAP TO SUPPORT
95
COTTER PIN STRAP TO CONSOLE
98
PAD FUEL TANK TO CONSOLE, ORDER BY THE METER
98
PAD FUEL TANK TO CONSOLE, ORDER BY THE METER
101
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
101
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
101
PAD , Replaced By: A6204750620
101
PAD , Replaced By: A6254750520
101
PAD FUEL TANK TO CONSOLE
104
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
104
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
107
BANJO UNION , Replaced By: N000000000363
110
SEAL RING FUEL LINE TO FEED PUMP
110
SEAL RING FUEL LINE TO FEED PUMP
110
SEAL RING FUEL LINE TO FEED PUMP
117
HOLLOW SCREW , Replaced By: N915036010108
117
HOLLOW SCREW FUEL LINE TO FEED PUMP
117
HOLLOW SCREW FUEL LINE TO FEED PUMP
117
HOLLOW SCREW FUEL LINE TO FEED PUMP
123
LINE FUEL COMPENSATING
123
LINE FUEL COMPENSATING
126
HOSE LEAK LINE
129
LOOM TIE , Replaced By: N916017011000
129
CLAMP , Replaced By: N916017011001
129
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
132
CLAMP , Replaced By: A1109950401
132
CLAMP FUEL LINE TO BRACKET
132
CLAMP , Replaced By: A3129952420
135
RUBBER PAD FUEL LINE TO BRACKET
138
SCREW FUEL COMPENSATING LINE TO REINFORCEMENT RAIL
141
WASHER , Replaced By: N009021005205
141
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
141
WASHER FUEL COMPENSATING LINE TO REINFORCEMENT RAIL
144
LOCK WASHER BRACKET TO STEERING COLUMN END
147
NUT , Replaced By: N304032005005
147
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
SENDER UNIT FUEL GAUGE
999
BRACKET FUEL LINE, 001434
999
STRAP ,5 149419, Replaced By: A6204700340, +001N000934012022
999
FUEL TANK , Replaced By: A3874701301
999
SUPPORT , Replaced By: A3874703342
999
STRAP FUEL TANK TO CONSOLE,5 149420
