Поз.
Артикул
Описание
168
PITMAN ARM FRONT
175
NUT PITMAN ARM TO STEERING BOX ASSEMBLY,5 386585
182
DRAG LINK , Replaced By: A3874603205
182
DRAG LINKLEMFOERDER,5 593344
182
DRAG LINKEHRENREICH,5 593344
189
BOOT DRAG LINK
196
DRAG LINK END , Replaced By: A0004602848
196
DRAG LINK END , Replaced By: A0014600848
196
DRAG LINK END , Replaced By: A0014602248
196
DRAG LINK END , Replaced By: A0014607748
196
DRAG LINK END R.H. THREAD EHRENREICH
196
DRAG LINK END , Replaced By: A0014601248, +001A0019905451
196
DRAG LINK END , Replaced By: A0014602248
196
DRAG LINK END R.H. THREAD EHRENREICH
203
BOOT DRAG LINK
210
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
210
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
217
SCREW , Replaced By: N308676012017
217
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
224
NUT SUPPORT TO SIDE MEMBER
231
NUT DRAG LINK TO LEVER
231
NUT DRAG LINK END M 24X1.5
238
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
245
DRAG LINK , Replaced By: A3914601905
245
DRAG LINK FROM PITMAN ARM TO STEERING SUPPORT I LEMFOERDER
245
DRAG LINK FROM PITMAN ARM TO STEERING SUPPORT I EHRENREICH
248
BOOT DRAG LINK
252
DRAG LINK , Replaced By: A6194604505
252
DRAG LINK FROM STEERING SUPPORT I TO STEERING SUPPORT II LEMFOERDER
252
DRAG LINK FROM STEERING SUPPORT I TO STEERING SUPPORT II EHRENREICH
255
BOOT DRAG LINK
273
NUT DRAG LINK TO LEVER
280
COTTER PIN DRAG LINK TO LEVER
350
STEERING SUPPORTI
357
STEERING INTERMEDIATE ARMI
385
SEAL RING INSIDE TO 622 463 01 10
392
SEAL RING INSIDE AND OUTSIDE TO 622 463 01 10
399
THRUST WASHER , Replaced By: A6574630162
406
NEEDLE BEARING INSIDE AND OUTSIDE
413
SPACER TUBE STEERING INTERMEDIATE ARM BEARING TO 622 461 00 40
413
SPACER TUBE INSIDE
420
SEAL RING , Replaced By: A0169973648
420
SEAL RING OUTSIDE TO 622 463 01 10
427
THRUST WASHER , Replaced By: A6574630062
434
GREASE NIPPLE , Replaced By: N071412008102
434
GREASE NIPPLE
441
NUT , Replaced By: N910113018004
441
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
448
SCREW , Replaced By: N308676016007
448
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
455
NUT , Replaced By: N910113016001
455
NUT CONSOLE TO SUPPORT
999
PROTECTIVE CAP
