Поз.
Артикул
Описание
103
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
103
U-BOLT FRONT SPRINGS TO FRONT AXLE 245 MM
103
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
103
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
108
NUT CROSS MEMBER TO REINFORCEMENT
108
NUT , Replaced By: N913004020003
109
BEARING BRACKET STABILIZER TO FRONT AXLE
109
CONSOLE ,5 910670, Replaced By: A6203230363, +001N000961012056
110
STUD BOLT
111
BEARING BRACKET RIGHT, TO BE ADAPTED DURING ASSEMBLY
113
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
114
NUT COMBINATION CYLINDER TO BEARING BRACKET
117
SCREW SUPPORT TO FENDER
117
SCREW , Replaced By: N304017008018
120
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
123
SHACKLE TORSION BAR,FRONT,5 165467
123
SHACKLE. LINK TORSION BAR
125
SHACKLE STABILIZER
126
BUSHING SHACKLE TO BEARING BRACKET
128
SPACER WASHER SHACKLE TO BEARING BRACKET
132
LOCK RING SHACKLE TO BEARING BRACKET,965965
138
TORSION BAR TRAILING AXLE STABILIZER
140
TORSION BAR
140
TORSION BAR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 5215065 903513, Replaced By: A6523230765
141
RUBBER MOUNTING SHACKLE TO TORSION BAR
142
BRACKET TORSION BAR
142
BRACKET , Replaced By: A6213230340
143
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
143
SCREW , Replaced By: N308676012012
144
NUT SUPPORT TO SIDE MEMBER
145
LOCK RING SHACKLE TO TORSION BAR
148
BEARING TORSION BAR,RIGHT,5 0251895 184731
148
BEARING TORSION BAR,LEFT,5 0251895 184731
154
BUSHING TORSION BAR TO BEARING BRACKET
154
BUSHING TORSION BAR TO BEARING BRACKET
157
WASHER TORSION BAR TO BEARING BRACKET
157
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
160
NUT CONSOLE TO SUPPORT
160
NUT , Replaced By: N910113016001
999
SCREW PLUG ,5 268773
999
NUT EXHAUST PIPE TO SIDE MEMBER
999
BUSHING
999
RUBBER BUFFER REAR SPRING
999
SHIM CONSOLE TO FRAME,123188
999
AIR SPRING BELLOWS PNEUMATIC SUSPENSION
999
SPACER TUBE PISTON TO CONSOLE
999
SHIM REAR SPRING
999
SPRING BOLT , Replaced By: A9463210071
999
BRACKET RUBBER BUFFER TO FRAME,5 282874
999
RUBBER BUFFER ,5 282874
999
SHACKLE PIN REAR SPRING TO REAR SPRING FRONT BRACKET
999
REPAIR KIT , Replaced By: A3893200165
999
PISTON TRAILING AXLE
999
PLATE AIR-SPRING-BELLOWS SUPPORT
999
RUBBER BUFFER TRAILING AXLE, UP TO IDENT NO.:5 318317, FROM IDENT NO. SEE MICROFICHE 420,435 GRUOP 32
999
SHIM TRAILING AXLE, UP TO IDENT NO.:5 318317, FROM IDENT NO. SEE MICROFICHE 420,435 GRUOP 32
999
BEARING BRACKET FRONT AXLE TORSION BAR
999
BUSHING
999
REAR SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: "6"
999
SCREWM 18X1.5X175
999
SCREW PLUG , Replaced By: N000908012009
999
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
999
SCREW BRACKET TO FRAME SIDE MEMBER
999
SCREW STEERING SUPPORT TO FRAME M 14X55
999
SCREW STEERING SUPPORT TO FRAME M 14X50
999
SCREW , Replaced By: N308676016005
999
SCREW , Replaced By: N308676012038
999
SCREW , Replaced By: N308676016005
999
SCREW , Replaced By: N308676016004
999
SEAL RING LINE CONNECTION
999
GREASE NIPPLE PROTECTIVE TUBE
999
SCREW BRACKET TO TRANSMISSION
999
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
999
SCREW SUPPORT TO TRANSMISSION M 16X1.5X60
999
NUT STRAP TO BRACKET
999
NUT STEERING SUPPORT TO FRAME
999
NUT FRONT SPRING TO SPRING BRACKET
999
NUT SHOCK ABSORBER TO FRONT SPRING, Replaced By: N910113022000
999
LOCK WASHERROCKINGER TYP 59 G140,59 G150
999
NUT , Replaced By: N910113010000
999
NUT , Replaced By: N910113014000
999
NUT TORSION BAR TO BEARING BRACKET,5 904661
999
NUT , Replaced By: N910113022001
