Поз.
Артикул
Описание
174
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
753
ADAPTER FITTING PASSAGE OF LINE THRU SIDE MEMBER,5 395033
753
ADAPTER FITTING , Replaced By: A0004296934
753
ADAPTER FITTING , Replaced By: A0004296634
754
NUT BRACKET TO SIDE MEMBER
758
FITTING DIAPHRAGM CYLINDER,CONNECTION:
760
FITTING DIAPHRAGM CYLINDER,CONNECTION:
762
UNION NUT LINE CONNECTION, Replaced By: N000000006239
764
SEAL CONE LINE CONNECTION
764
GLAND , Replaced By: A0019901967
766
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
766
CLAMP HOSE TO FITTING AND TO OIL TANK
770
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
772
SEAL RING BRAKE HOSE
772
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
780
WHEEL BRAKE CYLINDER TRISTOP CYLINDER GRAU
780
WHEEL BRAKE CYLINDER TRISTOP CYLINDER BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
780
WHEEL BRAKE CYLINDER TRISTOP CYLINDER WABCO
780
WHEEL BRAKE CYLINDER TRISTOP CYLINDER KNORR
785
BEARING BRACKET WHEEL CYLINDER
788
SCREW BEARING BRACKET TO REAR AXLE M 20X50, IN CASE OF CAST AXLE
788
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X40
788
SCREW , Replaced By: N308676016013
790
CLAMPING SLEEVE BEARING BRACKET TO REAR AXLE
792
NUT COMBINATION CYLINDER TO BEARING BRACKET
792
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
794
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
796
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
800
COTTER PIN STRAP TO SUPPORT
804
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
804
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
804
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
804
TEST CONNECTION
806
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
807
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
808
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
808
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
809
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
VALVETO 003 429 04 44,WABCO
999
REPAIR KIT PRESSURE RELIEF VALVE
999
REPAIR KITTO 000 429 27 95,WABCO
999
GUIDE , Replaced By: N071752014000
999
SEAL RINGKNORR
999
CUPTO 008 420 97 18, 008 420 90 18, BOSCH
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
VALVE TAPPETTO 002 429 96 44,VOSS
999
FILTER ELEMENTTO 000 429 28 95,GRAU
999
FILTER ELEMENT MAJOR TO 000 429 27 95,WABCO
999
FILTER ELEMENT MINOR TO 000 429 27 95,WABCO
999
DIAPHRAGM , Replaced By: A0004290745
999
THRUST WASHERTO 003 429 12 44,SCHAEFER
999
SEAL CONETO 003 429 12 44,SCHAEFER
999
DIAPHRAGM
999
FILTER ELEMENTTO 000 429 25 95,BOSCH
999
DIAPHRAGMTO 000 429 28 95,GRAU
999
DIAPHRAGMTO 000 429 25 95,BOSCH
999
SEAL RINGTO 002 429 96 44,VOSS
999
ADAPTER FITTING , Replaced By: A0069970072
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
REPAIR KITTO 000 429 26 95,KNORR
999
REPAIR KITTO 002 431 84 06, KNORR 90310
999
REPAIR KIT BRAKE POWER REGULATOR
999
REPAIR KIT , Replaced By: A0024209524, +002A0024209424
999
REPAIR KIT PRESSURE LIMIT VALVE
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
GASKET34X2X6 MM,GRAU
999
VALVE SEATGRAU
999
DIAPHRAGMTO 007 420 42 18,KNORR
999
DIAPHRAGMBOSCH,K 262627
999
VALVE
999
VALVEWABCO
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
SEALING CORDTO 000 429 27 95, WABCO
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
999
CONNECTOR REPAIR SIZE
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK ELECTRIC CABLE THRU CAB FLOOR
999
SCREW. UNION SCREW LINE CONNECTION
999
HANDLETO WABCO
999
HANDLEKNORR
999
PLUG
999
VALVE (RELAY VALVE) WABCO
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
VALVE (REGULATING VALVE),5 023386 TO BE ADAPTED DURING ASSEMBLY
999
REPAIR KIT TRISTOP CYLINDER TO 008 420 90 18, BOSCH
999
PROTECTIVE CAPTO WABCO
999
PROTECTIVE CAPTO BOSCH
999
PROTECTIVE CAPKNORR
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE WABCO, NOT USED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PRESSURE REGULATOR , Replaced By: A0024315006
999
VALVE , Replaced By: A0024312406
999
VALVE , Replaced By: A0024314006
999
PRESSURE REGULATOR , Replaced By: A0024314406
999
PRESSURE REGULATOR , Replaced By: A0024318406
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034315006
999
SEALING CORD38X8 MM
999
BANJO UNION BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
999
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
999
T-FITTING , Replaced By: A0029909070
999
T-FITTING LEFT AND RIGHT BRAKE HOSES
999
FITTING AIR RESERVOIR,CONNECTION: "11"
999
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
FITTING AIR RESERVOIR,CONNECTION: "13"
999
FITTING SHUTTLE VALVE,CONNECTION: "20"
999
SEAL RINGTO 000 429 25 95,BOSCH
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART KNORR,K 262627
999
REPAIR KIT. BRAKE CYLINDER DIAPHRAGM PART TO 007 420 42 18, KNORR
999
VALVE , Replaced By: A0034295344
999
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0034290844
999
VALVE (CHECK VALVE) VOSS
999
VALVE , Replaced By: A0024312706
999
VALVE (PRESSURE LIMIT VALVE)
999
VALVE , Replaced By: A0024319106
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 087820, Replaced By: A0034315006
999
PRESSURE REGULATORWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE , Replaced By: A0034315006
999
REPAIR KIT , Replaced By: A0004200871
999
REPAIR KITTO BOSCH
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
999
ELBOW FITTING , Replaced By: A0019908171
999
T-FITTING HOSE WIDTH, 9 MM,TO M 22
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
VALVE (CHECK VALVE) WABCO
999
VALVE , Replaced By: A0044293244
999
VALVE (CHECK VALVE) SCHAEFER
999
VALVE (RELAY VALVE) KNORR
999
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024296544
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
REPAIR KITTO 001 431 87 06,KNORR
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
VALVE (OVERFLOW VALVE) GRAU
999
SEAL RING , Replaced By: A0289972348
999
SPRINGTO 000 429 27 95,WABCO
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 429 28 95,GRAU
999
FITTING SHUTTLE VALVE,CONNECTION: "20",5 434013
999
SEAL RING34.6X2.6 MM
999
SEAL RING19.3X2.4 MM,TO 003 429 04 44,WABCO
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING28.4X2.6 MM
999
SEAL RING56X1.7 MM
999
SEAL RING , Replaced By: A0049972248
999
SEAL RING , Replaced By: A0009870746
999
SEAL RING13.6X2 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RING15.3X2.4 MM,TO 003 429 12 44,SCHAEFER
999
SEAL RINGTO 000 429 27 95, WABCO
999
WASHER BRACKET TO CROSS MEMBER,5 434013
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
BRACKET BRAKE POWER REGULATOR
999
ADHESIVE FOIL GUIDE SIGN
999
BRACKET LEFT FRONT
999
BRACKET BRAKE LINE MOUNTING
999
SEAL RING TO SEAL CABLE HARNESS OPENING IN CAB
999
LOCK BRAKE HOSE TO ANGLE
999
BRACKET , Replaced By: A6164290140
999
BRACKET , NOT USED
999
BRACKET LINE MOUNTING
999
STRAP AIR RESERVOIR TO BRACKET
999
STRAP AIR RESERVOIR III,5 088362
999
COVERING CHECK VALVE,5 298639
999
BRACKET AIR CLEANER,5 088361
999
BRACKET PRESSURE RATIO VALVE,5 180559
999
BRACKET PRESSURE RATIO VALVE,5 180559
999
BALL PIVOT BEARING BRACKET, IN CASE OF CAST AXLE
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
NUT , Replaced By: N308675016001
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
999
SCREW , Replaced By: N304017008039
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW HAND PUMP TO BRACKET
999
WASHER STRAP TO SUPPORT
999
CLAMPING SLEEVEKNORR
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEAL RING LINE CONNECTION
999
SEAL RING FUEL LINE TO FEED PUMP
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
SHEET METAL SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT 4,8X19
999
WASHER , Replaced By: N009021005205
