Поз.
Артикул
Описание
4
CABLE WINCH
4
CABLE WINCH
16
PAWL
20
SCREW END PIECE TO EXHAUST PIPE M 10X25
24
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
28
HEXAGON HEAD BOLT SUPPORTING ARM TO TIMING CASE M 16X40
28
SCREW SUPPORTING ARM TO TIMING CASE M 16X40, Replaced By: N304017016008
28
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
28
SCREW , Replaced By: N308676012011
28
SCREW , Replaced By: N308676012031
32
SCREWM 16X110
36
LOCK WASHERROCKINGER TYP 59 G140,59 G150
40
NUTM 16
40
NUT SUPPORT TO SIDE MEMBER
44
WIRE CABLE16 MMX60 M
48
BRAKE BANDKOMPLETT
56
PAD CABLE WINCH TO FRAME SIDE MEMBER
57
BRACKET ROD TO SIDE MEMBER
58
BRACKET ROD TO SIDE MEMBER
60
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
60
SCREW , Replaced By: N308676016014
60
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
64
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
64
SCREW , Replaced By: N308676016007
68
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
68
SCREW , Replaced By: N308676016006
72
SCREW HYDRAULIC MOTOR AND CABLE WINCH TO FRAME SIDE MEMBER M 16X40
72
SCREW , Replaced By: N914141016001
74
SCREW CABLE WINCH TO FRAME SIDE MEMBER M 16X35
76
SCREW HYDRAULIC MOTOR AND CABLE WINCH TO FRAME SIDE MEMBER M 16X30
78
SCREW CABLE WINCH TO FRAME SIDE MEMBER M 16X25
80
NUT CONSOLE TO SUPPORT
80
NUT , Replaced By: N910113016001
84
BRACKET CABLE WINCH
84
BRACKET CABLE WINCH
88
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
88
SCREW , Replaced By: N308676016006
88
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
88
SCREW , Replaced By: N308676016007
92
SCREW HYDRAULIC MOTOR AND CABLE WINCH TO FRAME SIDE MEMBER M 16X30
96
NUT CONSOLE TO SUPPORT
96
NUT , Replaced By: N910113016001
100
HYDRAULIC MOTOR
100
HYDRAULIC MOTOR
104
VALVE
108
SEAL RING
112
SCREW
116
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
120
FITTING
124
ELBOW FITTING
128
T-FITTING
132
FITTING
136
ELBOW FITTING
140
FITTING
144
OIL LINE
148
OIL LINE
152
FITTING
156
COUPLING
160
LOCK RING SHACKLE TO CONSOLE TO 393 326 00 63,965965
164
SEAL RING
168
PUMP
172
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
172
SCREW , Replaced By: N304017008016
176
SCREW FLANGE TO TRANSMISSION CASE
180
SCREW STRAP TO BRACKET
184
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
184
SCREW , Replaced By: N308676016007
184
SCREW ENGINE MOUNTING TO SUPPORTING ARM
188
SCREW HYDRAULIC MOTOR AND CABLE WINCH TO FRAME SIDE MEMBER M 16X30
188
SCREW HYDRAULIC MOTOR AND CABLE WINCH TO FRAME SIDE MEMBER M 16X40
188
SCREW , Replaced By: N914141016001
192
NUT CONSOLE TO SUPPORT
192
NUT , Replaced By: N910113016001
999
BRACKET RIGHT TAIL LAMP
999
BRACKET PULL ROD
999
OIL LINE FROM PUMP TO HYDRAULIC MOTOR
999
OIL LINE FROM PUMP TO HYDRAULIC MOTOR
999
OIL LINE FROM PUMP TO HYDRAULIC MOTOR
999
OIL LINE FROM PUMP TO HYDRAULIC MOTOR
999
WASHER , Replaced By: N009021008213
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
999
SCREW CROSS MEMBER TO REINFORCEMENTS AND TO SIDE MEMBERS M 16X45,5 253792
