Поз.
Артикул
Описание
14
FLEXIBLE METAL TUBE FRONT LEFT
20
COLLAR (SLIDING COLLAR)
32
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
35
SCREW , Replaced By: N304017008028
35
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
44
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
44
NUT , Replaced By: N913004008001
44
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
47
EXHAUST PIPE FRONT EXHAUST PIPE,RIGHT,Z 902909
50
EXHAUST PIPE
59
SCREW CONNECTOR TO REAR SHIFTING ROD
59
SCREW , Replaced By: N304017010047
65
NUT , Replaced By: N910113010000
65
NUT STRAP TO BRACKET
71
CLAMP EXHAUST PIPE TO BRACKET
74
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
77
SCREW , Replaced By: N304017010002
77
SCREW EXHAUST PIPE TO BRACKET
77
SCREW BRACKET TO SIDE MEMBER
80
NUT STRAP TO BRACKET
80
NUT , Replaced By: N910113010000
86
EXHAUST MUFFLER
188
REAR EXHAUST PIPE (TAIL PIPE)
191
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
194
SCREW BRACKET TO SIDE MEMBER
194
SCREW , Replaced By: N304017010002
197
NUT , Replaced By: N910113010000
197
NUT STRAP TO BRACKET
215
PROTECTIVE PLATE REAR EXHAUST PIPE, NOT USED
218
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
218
CLAMP , Replaced By: N071555100501
221
SCREW , Replaced By: N304017010002
221
SCREW BRACKET TO SIDE MEMBER
224
NUT STRAP TO BRACKET
224
NUT , Replaced By: N910113010000
