Поз.
Артикул
Описание
119
UNION NUT LINE CONNECTION
122
UNION NUT LINE CONNECTION
122
UNION NUT LINE CONNECTION, Replaced By: N000000006239
125
GLAND LINE CONNECTION
128
SEAL CONE LINE CONNECTION
128
GLAND , Replaced By: A0019901967
131
FITTING (DELIVERY LINE),FROM PUMP TO STEERING, Replaced By: A9329970772
131
FITTING , Replaced By: N003952015100
131
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
131
T-FITTING SUPPLY LINE FOR TRANSMISSION
131
FITTING DELIVERY LINE TO PUMP
131
T-FITTING POWER STEERING
131
FITTING OIL LINE CONNECTION
131
FITTING (PARTS KIT),LINE RUPTURE
131
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
155
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
158
SEAL RING VALVE TO VALVE,K 025179
160
HOSE , NOT USED
173
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
173
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
173
CLAMP HOSE TO FITTING AND TO OIL TANK
173
CLAMP , Replaced By: N000000000667
194
UNION NUT LINE CONNECTION
197
GLAND LINE CONNECTION
500
BRACKET CLUTCH AND BRAKE HOSES,4 276783
557
CLAMP DELIVERY AND SUCTION LINES TO STEERING
557
CLAMP FEED LINE TO THERMOSTAT
557
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
557
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
557
CLAMP LINE MOUNTING
557
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
557
CLAMP , Replaced By: A6739950001
560
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
560
CLAMP LINE MOUNTING
560
CLAMP HOSE TO FLANGE AND TO VALVE
560
CLAMP OIL DIPSTICK TO RADIATOR
560
CLAMP DELIVERY AND SUCTION LINES TO FRAME
560
CLAMP FRAME MOUNTED CABLE HARNESS TO CAB
560
CLAMP OIL FILLER PIPE TO BRACKET
560
CLAMP LINES TO BRACKET
563
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
563
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
563
CLAMP HOSE TO FITTING AND TO OIL TANK
563
CLAMP , Replaced By: N000000000667
581
SCREW , Replaced By: N304017006018
581
SCREW , Replaced By: N304017006020
581
SCREW , Replaced By: N304017006016
581
SCREW PUMP TO BRACKET
581
SCREW BRACKET ON LOAD SENSOR
581
SCREW COVER PLATE TO COVER PLATE M 6 X 12
581
SCREW COVER PLATE TO BRACKET
581
SCREW CAB FLOOR COVERING M 6X25
581
SCREW LICENSE PLATE TO BRACKET
593
NUT PUMP TO BRACKET
593
NUT , Replaced By: N913004006001
596
LOOM TIE LINE MOUNTING
999
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
999
BRACKET DELIVERY AND SUCTION LINES TO FRAME
