Поз.
Артикул
Описание
5
RADIATOR WITH SCREW FITTING
5
RADIATOR , FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHE, Replaced By: A6525016601, +001A6552602262, +001A6552602985, +001A6552603085, +001A6559974182, +001A6559974682
8
BRACKET RADIATOR
11
RUBBER MOUNTING RADIATOR
14
TAPPING SCREW BRACKET TO RADIATOR
17
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
18
SPRING WASHER LICENSE PLATE TO BRACKET
20
WASHER STRUT TO CROSS MEMBER
20
WASHER , Replaced By: N007349010007
41
RADIATOR OIL COOLER TO RADIATOR
44
BRACKET OIL COOLER TO BRACKET,BOTTOM
47
BRACKET OIL COOLER TO BRACKET,TOP
50
SCREW BRACKET TO RADIATOR
53
THREADED UNION BRACKET TO OIL COOLER,TOP
56
SCREW REDUCTION VALVE TO BRACKET
56
SCREW , Replaced By: A0079900801
59
SCREW , Replaced By: N304017008021
59
SCREW , Replaced By: N304017008021
59
SCREW PIPE CLAMP
62
SPRING WASHER , Replaced By: N000137008212
62
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
65
WASHER EXHAUST MUFFLER TO STRAP
65
WASHER , Replaced By: N000125008443
113
COOLER FUEL
116
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
119
BRACKET FUEL TANK
125
WASHER , Replaced By: N000125008443
125
WASHER EXHAUST MUFFLER TO STRAP
128
SCREW PIPE CLAMP
128
SCREW , Replaced By: N304017008021
131
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
134
NUT , Replaced By: N913004008001
134
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
134
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
137
BRACKET OIL COOLER,LEFT BOTTOM
140
BRACKET OIL COOLER,RIGHT BOTTOM
143
BRACKET OIL COOLER TO RADIATOR
144
BRACKET OIL COOLER TO RADIATOR
145
EDGE GUARD SECTION AT SHOCK ABSORBER BRACKET, ORDER BY THE METER
145
EDGE GUARD SECTION SEAT, Replaced By: A0019872272
145
EDGE GUARD SECTION , Replaced By: A0029873572
146
SCREW , Replaced By: N304017006018
146
SCREW COVER PLATE TO COVER PLATE M 6 X 12
149
NUT PUMP TO BRACKET
149
NUT , Replaced By: N913004006001
150
SEAL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A2106280098
150
SEAL , TO BE ADAPTED DURING ASSEMBLY
158
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
158
SCREW , Replaced By: N308676014020
161
SCREW DE-AERATION LINE TO RADIATOR
161
SCREW EXHAUST PIPE AND PIPE CLAMP TO BRACKET
167
RADIATOR (OIL COOLER),FAN DRIVE
170
TANK EXPANSION TANK
173
RADIATOR CAP CENTRAL
173
RADIATOR CAP CENTRAL
176
RADIATOR CAP
179
RADIATOR CAP FILLER NECK
179
RADIATOR CAP FILLER NECK
182
GASKET O.D., 52 MM
185
GASKET O.D., 37 MM
188
CLAMP EXPANSION TANK TO SUPPORT
