Поз.
Артикул
Описание
5
HOSE FROM OIL TANK TO SUCTION LINE
5
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
8
CLAMP , Replaced By: N000000000667
8
CLAMP HOSE TO FITTING AND TO OIL TANK
8
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
8
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
11
BANJO UNION. LINE (SUCTION LINE),FROM OIL TANK TO PUMP
12
BANJO UNION
14
LINE (SUCTION LINE) FROM OIL TANK TO PUMP,CIRCUIT II,5 7647845 760760
14
LINE (SUCTION LINE) FROM OIL TANK TO PUMP,CIRCUIT II,K 139876
14
LINE (SUCTION LINE) FROM OIL TANK TO PUMP,CIRCUIT II
14
LINE (SUCTION LINE) FROM OIL TANK TO PUMP,CIRCUIT II
14
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
14
LINE ,K 053632
14
LINE (PRESSURE LINE),PUMP TO SEPARATION POINT ENGINE CIRCUIT II
14
LINE , Replaced By: A0004291601
17
UNION NUT LINE CONNECTION, Replaced By: N000000006243
17
NUT LINE CONNECTION
20
SEAL CONE LINE CONNECTION
20
GLAND , Replaced By: A0019901267
23
HOLLOW SCREW SUCTION LINE TO OIL PUMP
26
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
29
FITTING POWER STEERING PUMP TO BEARING FLANGE
32
SEAL RING POWER STEERING PUMP TO BEARING FLANGE
34
FITTING SUCTION LINE TO OIL PUMP
41
SEAL RING LINE CONNECTION
41
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
44
FITTING POWER STEERING PUMP TO BEARING FLANGE
47
SEAL RING POWER STEERING PUMP TO BEARING FLANGE
50
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
53
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
56
SCREW CONNECTION DELIVERY LINE TO PUMP
65
SEAL RING LINE CONNECTION
68
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
71
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
74
SEAL RING LINE CONNECTION
75
LINE (PRESSURE LINE),PUMP TO SEPARATION POINT ENGINE CIRCUIT II
75
LINE DELIVERY LINE TO OIL PUMP,CIRCUIT II,5 7324635 764783
75
LINE DELIVERY LINE TO OIL PUMP,CIRCUIT II
75
LINE DELIVERY LINE TO OIL PUMP,CIRCUIT II,5 760761K 053631
75
LINE DELIVERY LINE TO OIL PUMP,CIRCUIT II,K 053632
75
LINE DELIVERY LINE TO OIL PUMP,CIRCUIT II,5 704174
75
LINE DELIVERY LINE TO OIL PUMP,CIRCUIT II,5 764784
75
LINE DELIVERY LINE TO OIL PUMP,CIRCUIT II,K 139876
522
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
525
CLAMP FEED LINE TO THERMOSTAT
525
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
525
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
525
CLAMP DELIVERY AND SUCTION LINES TO STEERING
525
CLAMP BRACKET TO ACCUMULATOR
528
CLAMP DELIVERY AND SUCTION LINES TO FRAME
528
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
528
CLAMP LINE MOUNTING
528
CLAMP LINES TO BRACKET
528
CLAMP ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
528
CLAMP HOSE TO FLANGE AND TO VALVE
528
CLAMP OIL DIPSTICK TO RADIATOR
528
CLAMP FRAME MOUNTED CABLE HARNESS TO CAB
528
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
537
SCREW , Replaced By: N304017006020
537
SCREW , Replaced By: N304017006018
537
SCREW OIL LINE TO CRANKCASE
537
SCREW COVER PLATE TO BRACKET
537
SCREW CAB FLOOR COVERING M 6X25
537
SCREW RADIATOR M 10X45
537
SCREW LICENSE PLATE TO BRACKET
537
SCREW PUMP TO BRACKET
537
SCREW COVER PLATE TO COVER PLATE M 6 X 12
543
SPRING WASHER LICENSE PLATE TO BRACKET
543
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
546
NUT STRAP TO BRACKET
546
NUT , Replaced By: N910113010000
546
NUT , Replaced By: N913004006001
546
NUT PUMP TO BRACKET
999
CLAMP , Replaced By: N916016015202
999
CONNECTION FITTING
999
SCREW , Replaced By: N304017006016
999
HOSE , Replaced By: A3859971682
999
SPRING , Replaced By: A0029935201
999
HOSE , Replaced By: A3849977482
999
BRACKET , Replaced By: A6194660740
999
BRACKET PRESSURE LIMIT VALVE
999
BRACKET LINES TO SIDE MEMBER
999
BRACKET CUT-IN VALVE
999
BRACKET , Replaced By: A6735460443
999
BRACKET OIL LINE TO ENGINE,5 704175
999
BRACKET LINES TO SIDE MEMBER
999
BRACKET POWER CYLINDER DELIVERY LINE,5 556098
999
HOSE , Replaced By: A6254660281
999
HOSE , Replaced By: A6254660281
999
HOSE ,5 760761, Replaced By: A6254660381
999
BRACKET OIL LINE ON ENGINE SIDE
999
HOSE , NOT USED
999
CLAMP , Replaced By: A6739950001
999
CLAMP LINE MOUNTING
999
FITTING , Replaced By: A3529971171
999
FITTING (PARTS KIT),LINE RUPTURE
999
PISTON , Replaced By: A0004665783
999
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004664291
999
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004664291
