Поз.
Артикул
Описание
5
TANK OIL
8
CONNECTORTO 000 466 38 02
11
SEAL RINGTO 000 466 38 02
14
WASHER HYDRAULIC CYLINDER TO SWIVEL ARM
20
SPRING BRAKE ANCHOR
23
SUPPORT FILTER ELEMENT
26
FILTER , 993034
29
SPACER TUBE OIL FILTER
32
RUBBER SLEEVETO 000 466 38 02
35
COVERTO 000 466 38 02
38
SEAL RINGTO 000 466 38 02
41
NUTTO 000 466 38 02
44
OIL DIPSTICK
47
SCREW JUNCTION BOX TO BRACKET
47
SCREW , Replaced By: N000000001149
47
SCREW , Replaced By: A0029903712
47
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
50
NUT , Replaced By: N913004006001
50
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
50
NUT , Replaced By: N913004008001
50
NUT PUMP TO BRACKET
50
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
53
BRACKET OIL TANK
59
BRACKET BRACKET TO BRACKET
59
BRACKET OIL TANK
62
COVER PLATE OIL TANK
83
SCREW REAR EXHAUST PIPE TO MUFFLER
83
SCREW BRACKET TO COVERING
83
SCREW CLAMP TO BRACKET M 6X14
83
SCREW BRACKET TO OIL TANK M 16X80
83
SCREW , Replaced By: N000000001149
83
SCREW , Replaced By: A0029903712
83
SCREW , Replaced By: N000000001145
83
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
89
NUT , Replaced By: N913004006001
89
NUT , Replaced By: N910113010000
89
NUT STRAP TO BRACKET
89
NUT PUMP TO BRACKET
95
BRACKET OIL TANK
999
VALVE DISC , 993034
999
BRACKET , Replaced By: A6254601335
999
BRACKET , Replaced By: A6254601935
