3235,3235K 625.120

32 SPRINGS AND SUSPENSION - 001 EXHAUST MUFFLER IN FRONT OF FRONT AXLE IL.5

Поз.
Артикул
Описание
10
A6255220301
FENDER , Replaced By: A0005220401
10
A6255220201
FENDER , Replaced By: A0005220401
10
A0005220401
FENDER STEERED AXLE,5 952572
20
A3815220001
FENDER
30
A6205205241
BRACKET FENDER
40
A6205204341
BRACKET FENDER TO BRACKET
50
A6205220020
CLAMPING PIECE
60
N007341008117
RIVET
70
A6209900023
SCREW
80
N006331008001
NUT
90
A3935220029
REINFORCEMENT FENDER
100
N000603006063
SCREW BRACKET TO REAR FENDER
110
N009021006205
WASHER , Replaced By: N009021006208
110
N009021006208
WASHER COMPRESSED AIR LINE TO BRACKET
120
N000934006007
NUT BALL PIVOT TO LEVER
130
A3818810905
SPLASH GUARD FENDER
140
A3818810406
RAIL FENDER TO BODY
150
N007985006581
SCREW CLAMP TO BRACKET
150
N007985006172
SCREW , Replaced By: N007985006581
160
N000125006421
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
160
N000125006449
WASHER COMPRESSED AIR LINE TO BRACKET
170
N913004006001
NUT PUMP TO BRACKET
170
N913004006002
NUT , Replaced By: N913004006001
180
A3875220292
BEARING BRACKET , 393.311 UP TO CHASSIS 4 450302,393.321 UP TO CHASSIS 4 453 074,395.312,322,412,422 UP TO CHASSIS 4 426005
190
A6235210049
MOUNTING PLATE FRONT FENDER
200
N000933012071
SCREW BRACKET TO SIDE MEMBER M 12X40
210
N304017010002
SCREW BRACKET TO SIDE MEMBER
210
N000931010264
SCREW RADIATOR M 10X45
210
N000933010129
SCREW , Replaced By: N304017010002
210
N000933010094
SCREW EXHAUST PIPE TO BRACKET
210
N000933010145
SCREW REAR EXHAUST PIPE TO MUFFLER
220
N308676012014
HEXAGON HEAD BOLT BRACKET TO CROSS MEMBER
230
N000931008251
SCREW REAR AXLE REGULATING SOLENOID VALVE
240
N913002012004
NUT END PIECE TO EXHAUST PIPE
250
N913004010008
NUT , Replaced By: N910113010000
250
N910113010000
NUT STRAP TO BRACKET
260
N910113012003
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
260
N913004012009
NUT , Replaced By: N910113012003
270
N913004008001
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
270
N913004008004
NUT , Replaced By: N913004008001
280
A3665220249
ANGLE. SUPPORT , Replaced By: A3935220140
280
A3935220140
BRACKET LEFT AND RIGHT,5 453765
290
A6525223040
BRACKET RIGHT TAIL LAMP, UP TO IDENT NO. K 279038, FROM IDENT NO. SEE STANDARD VERSION
290
A6255223440
BRACKET CENTRAL,LEFT,AND RIGHT, TO BE ADAPTED DURING ASSEMBLY
290
A6255223140
BRACKET , Replaced By: A6525223240
290
A6255221840
BRACKET , Replaced By: A6525222840
290
A6225220240
BRACKET , Replaced By: A6525222240
290
A6225220140
BRACKET , Replaced By: A6525222240
290
A3915220440
BRACKET , Replaced By: A6525222240
290
A6525222640
BRACKET TAIL LAMP
290
A6525223240
BRACKET FENDER TO BEARING BRACKET, FRONT
290
A6525222240
BRACKET TAIL LAMP
290
A6525222840
BRACKET LEFT AND RIGHT FRONT
300
A0009970620
EXPANSION PLUG BRACKET
999
A6255222140
BRACKET
999
A6235221740
BRACKET , Replaced By: A6525222640
