Поз.
Артикул
Описание
5
FUEL TANK
5
FUEL TANK , Replaced By: A3874701001
10
FILLER CAP , Replaced By: A0004700305
10
FILLER CAP , Replaced By: A0004717930
10
FILLER CAP , Replaced By: A0004700305
10
FILLER CAP , Replaced By: A0004700305
10
FILLER CAP
15
SEAL RING
18
CHAIN FILLER CAP
20
FUEL STRAINER FUEL TANK,K 169122
25
FILLER CAP IN PLACE OF FUEL GAUGE SENDER UNIT
30
SENDER UNIT , Replaced By: A0085428117
30
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A0115426517, +001A0005409917
35
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
40
SCREW PLUG , Replaced By: N007604014110
40
SCREW PLUG FUEL TANK
45
SEAL RING FUEL LINE TO FEED PUMP
140
GROMMET AIR SPRING VALVE
145
LINE FUEL COMPENSATING
150
HOSE LEAK LINE
155
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
155
CLAMP , Replaced By: N916017011001
160
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
165
BANJO UNION , Replaced By: N000000000363
165
BANJO UNION FEED
170
HOLLOW SCREW FUEL LINE TO FEED PUMP
170
HOLLOW SCREW , Replaced By: N915036010108
175
SEAL RING FUEL LINE TO FEED PUMP
180
INSULATING HOSE FEED 11X0.7 MM, ORDER BY THE METER
185
SLEEVE FEED
185
CONNECTOR RIGHT,177-LITER
190
FITTING RETURN
195
UNION NUT FUEL LINE
200
CLAMP FUEL LINE TO BRACKET
200
CLAMP , Replaced By: A3129952420
200
CLAMP , Replaced By: A1109950401
205
RUBBER PAD FUEL LINE TO BRACKET
210
SCREW , Replaced By: N007985005175
210
SCREW HOOK TO BRACKET
215
WASHER , Replaced By: N009021005205
215
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
220
LOCK WASHER BRACKET TO STEERING COLUMN END
225
NUT , Replaced By: N304032005005
225
NUT IN CASE OF SUBSEQUENT INSTALLATION
230
LOOM TIE LINE MOUNTING
230
LOOM TIE LINE MOUNTING 280 MM
999
CONSOLE , Replaced By: A3354750703
999
CONSOLE REAR EXHAUST PIPE TO CONSOLE
999
SUPPORT FRONT FUEL TANK
