Поз.
Артикул
Описание
164
LINE CLUTCH LINE
168
LINE FROM VALVE TO CONNECTION FITTING 1500 MM, TO BE ADAPTED DURING ASSEMBLY
170
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
170
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
172
LINE FROM MASTER CYLINDER TO HOSE 95 MM,K 130133
174
UNION NUT LINE CONNECTION
174
UNION NUT
176
GLAND LINE CONNECTION
178
LINE FROM MASTER CYLINDER TO PARTITION FITTING 4150 MM
178
LINE FROM MASTER CYLINDER TO PARTITION FITTING 5000 MM
182
FITTING (PARTS KIT),LINE RUPTURE
244
BRACKET CLUTCH LINE TO BRACKET,K 130132
245
FITTING HYDRAULIC LINE TO BRACKET,K 130132
249
BRACKET HYDRAULIC LINE TO FAN SHROUD
251
ANGLE LINE MOUNTING
260
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
269
CLAMP WIRE CABLE TO SIDE MEMBER AND TO TRANSMISSION
269
CLAMP LINE MOUNTING
269
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
269
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
269
CLAMP ,K 147121, Replaced By: N000000000319
272
SCREW , Replaced By: N304017006016
272
SCREW PUMP TO BRACKET
272
SCREW COVER PLATE TO BRACKET
275
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
278
NUT , Replaced By: N913004006001
278
NUT PUMP TO BRACKET
