Поз.
Артикул
Описание
5
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
5
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
8
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
9
PLASTIC PIPE RISING PIPE 4X6 MM
9
PLASTIC PIPE RISING PIPE 4X6 MM
10
PLASTIC PIPE AERATION, ORDER BY THE METER
11
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
11
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
12
PLASTIC PIPE FUEL LINE 16X2 MM, ORDER BY THE METER
13
INSULATING HOSE FEED 11X0.7 MM, ORDER BY THE METER
13
INSULATING HOSE FEED 11X0.7 MM, ORDER BY THE METER
14
HOSE LEAK LINE
14
HOSE LEAK LINE
17
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
17
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
20
SLEEVE FEED
20
SLEEVE FEED
23
CLIP LEAK LINE
26
CLAMP , Replaced By: N000000000665
26
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
26
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
29
BANJO UNION FEED
29
BANJO UNION FEED
29
BANJO UNION , Replaced By: N000000000363
32
HOLLOW SCREW FUEL LINE TO FEED PUMP
32
HOLLOW SCREW FUEL LINE TO FEED PUMP
32
HOLLOW SCREW , Replaced By: N915036010108
35
SEAL RING FUEL LINE TO FEED PUMP
35
SEAL RING FUEL LINE TO FEED PUMP
38
FITTING RETURN
38
FITTING RETURN
41
NUT. UNION NUT RETURN
44
ELBOW FITTING RETURN
44
ELBOW FITTING RETURN
47
LOOM TIE LINE MOUNTING 280 MM
47
LOOM TIE LINE MOUNTING 280 MM
47
LOOM TIE LINE MOUNTING
50
BRACKET TRANSMISSION,REAR
53
BRACKET FUEL LINE TO BELL HOUSING
53
BRACKET FUEL LINE TO BELL HOUSING
999
BRACKET AT FRAME
999
SCREW , Replaced By: N304017008027
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
