Поз.
Артикул
Описание
5
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
8
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
8
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
11
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
14
UNION NUT LINE CONNECTION
14
UNION NUT LINE CONNECTION
17
GLAND LINE CONNECTION
17
GLAND LINE CONNECTION
20
SLEEVE LINE CONNECTION
20
SLEEVE LINE CONNECTION
23
FITTING (PARTS KIT),LINE RUPTURE
26
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
26
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
26
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
26
BANJO UNION HEATING CONNECTION,K 169122
26
BANJO UNION HEATING CONNECTION,K 169122
26
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
29
ELBOW FITTING HOSE WIDTH, 6 MM,TO M22
29
ELBOW FITTING , Replaced By: A0049905371
32
T-FITTING
32
T-FITTING
35
COUPLING COMPRESSED AIR PIPING,YB227219
35
COUPLING COMPRESSED AIR PIPING,YB227219
38
PLUG COMPRESSED AIR PIPING,YB227219
38
PLUG COMPRESSED AIR PIPING,YB227219
41
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
45
PLASTIC PIPE RISING PIPE 4X6 MM
45
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
45
PLASTIC PIPE RISING PIPE 4X6 MM
48
UNION NUT
48
UNION NUT
51
SEAL CONE
51
GLAND , Replaced By: A0019901667
54
SLEEVE LEAK LINE
57
TS DOUBLE FITTING (PARTS KIT),LINE RUPTURE 4MM
57
TS DOUBLE FITTING (PARTS KIT),LINE RUPTURE 4MM
60
INSULATING HOSE PROTECTION AGAINST SCORING 10 MM, SILIKON / SILICONE, ORDER BY THE METER
60
INSULATING HOSE PROTECTION AGAINST SCORING 10 MM, SILIKON / SILICONE, ORDER BY THE METER
60
INSULATING HOSE PROTECTION AGAINST SCORING 10 MM, SILIKON / SILICONE, ORDER BY THE METER
60
INSULATING HOSE PROTECTION AGAINST SCORING 10 MM, SILIKON / SILICONE, ORDER BY THE METER
63
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
63
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
63
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
63
BANJO UNION , Replaced By: N000000000364
66
ELBOW FITTING
66
ELBOW FITTING
66
ELBOW FITTING
66
ELBOW FITTING
66
ELBOW FITTING. T-FITTING LINE CONNECTION TO ENGINE TO M16
66
ELBOW FITTING. T-FITTING LINE CONNECTION TO ENGINE TO M16
66
ELBOW FITTING. T-FITTING LINE CONNECTION TO ENGINE TO M16
66
ELBOW FITTING. T-FITTING LINE CONNECTION TO ENGINE TO M16
69
COUPLING COMPRESSED-AIR-LINE PLUG-CONNECTION
72
PLUG COMPRESSED-AIR-LINE PLUG-CONNECTION
72
COUPLING COMPRESSED-AIR-LINE PLUG-CONNECTION 4 MM
72
COUPLING COMPRESSED-AIR-LINE PLUG-CONNECTION 4 MM
72
PLUG COMPRESSED-AIR-LINE PLUG-CONNECTION
75
CONNECTOR DISTRIBUTOR MIDDLE, COMPRESSED AIR LINE PLUG CONNECTION, WITH THROTTLE
75
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO 008 997 90 82
75
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO 008 997 90 82
75
CONNECTOR DISTRIBUTOR MIDDLE, COMPRESSED AIR LINE PLUG CONNECTION, WITH THROTTLE
75
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO 008 997 90 82
75
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO 008 997 90 82
78
SEAL RING CONNECTOR 11.8X2 MM
78
SEAL RING CONNECTOR 11.8X2 MM
81
T-FITTING 3/2-WAY VALVE,CONNECTIONS: "30,50"
81
T-FITTING 3/2-WAY VALVE,CONNECTIONS: "30,50"
81
T-FITTING , Replaced By: A0009902670
84
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
84
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
84
T-FITTING BETWEEN THE LINES
86
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
86
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
89
HOLLOW SCREW HEATING CONNECTION
89
HOLLOW SCREW HEATING CONNECTION
180
ELBOW FITTING
180
ELBOW FITTING
180
ELBOW FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
180
ELBOW FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
216
LOOM TIE LINE MOUNTING 280 MM
216
LOOM TIE LINE MOUNTING 280 MM
999
VALVE (3/2-WAY SOLENOID VALVE) WABCO
999
VALVE 3/2-WAY, EXHAUST BRAKE CONTROL WABCO
999
BRACKET 3/2-WAY VALVE
999
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
HOLLOW SCREW , Replaced By: N915036010108
