Поз.
Артикул
Описание
412
HOUSING TRANSMISSION CONNECTION
416
GASKET , Replaced By: A0002575280
416
GASKET CASE TO BELL HOUSING
420
BREATHER , Replaced By: A3432640089
424
SCREW PLUG OIL COOLER,5 360280
424
SCREW PLUG , Replaced By: N000908026008
424
SCREW PLUG , Replaced By: A0009973532
428
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
432
FLANGE HOUSING,BOTTOM
436
SEAL RING OIL LINES TO TRANSMISSION
436
SEAL RING , Replaced By: A0119973448
440
SCREW 4/2-WAY VALVE TO BRACKET
444
SCREW PLUG OIL FILLING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
448
SCREW OIL DRAIN
452
SEAL RING OIL COOLER CONNECTION
456
SCREW VALVE TO BRACKET
464
SHAFT (OUTPUT SHAFT)
468
WASHER OUTPUT SHAFT
472
SEAL RING OUTPUT SHAFT
476
SEAL RING OUTPUT SHAFT
480
CYLINDR. ROLLER BEARING OUTPUT SHAFT
480
CYLINDR. ROLLER BEARING , Replaced By: A0059814101
484
LOCK RING DRIVE GEAR
488
SEAL RING DRIVE SHAFT 70X85X8 MM, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
492
SEAL RING , Replaced By: A0079976047
496
COUPLING FLANGE
500
SCREW , Replaced By: A3609903001
500
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
504
SCREW END PIECE TO EXHAUST PIPE M 10X25
508
THRUST WASHER FLANGE TO SHAFT
512
LOCK , Replaced By: A0002640273
512
LOCK FLANGE TO SHAFT
516
BRACKET RELEASE LEVER
520
SCREW SHIFTING ROD TO JOINT
524
BUSHING RELEASE LEVER TO BRACKET
528
BEARING RELEASE LEVER
532
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
532
NUT , Replaced By: N308673012002
536
RELEASE LEVER , Replaced By: A0002501013
536
RELEASE LEVER CLUTCH BOOSTER
540
RACE RELEASE LEVER
544
BUSHING RELEASE LEVER
552
FLANGE MASTER CYLINDER TO BELL HOUSING
556
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
556
SCREW , Replaced By: N304014008004
556
SCREW , Replaced By: N304014008001
560
SPRING WASHER , Replaced By: N000137008212
560
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
564
MASTER CYLINDER , Replaced By: A0012954706
564
MASTER CYLINDER CLUTCH
568
PISTONWABCO 470 051 10 60
572
VALVE CLUTCH SLAVE CYLINDER
572
SCREW (BLEEDER SCREW)
572
VALVE , Replaced By: A3075530107
572
VALVE , Replaced By: A0000610271
576
PROTECTIVE CAP , Replaced By: A0004217187
576
PROTECTIVE CAP ,5 962906
580
BOOT
584
REPAIR KIT MASTER CYLINDER
588
SCREW FRONT AXLE REGULATING SOLENOID VALVE
588
SCREW , Replaced By: N304014008007
592
SCREW , Replaced By: N304017008027
592
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
596
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
596
SPRING WASHER , Replaced By: N000137008212
600
SENDER UNIT INDUCTIVE,ENGINE SPEED AND TURBINE SPEED
604
SPACER WASHER AS REQUIRED 0.20 MM
604
WASHER , Replaced By: A3022050152
604
WASHER AS REQUIRED 0.30 MM
604
WASHER AS REQUIRED 1.00 MM
608
ELECTRIC CABLE , Replaced By: A0005468114
608
ELECTRIC CABLE FROM INDUCTIVE PICKUP TO PLUG CONNECTION IN CASE
610
GASKET
612
GUIDE CONVERTER HOUSING
616
GASKET
620
SCREW CABLE TO SHELL
624
CLAMP CABLE TO TRANSMISSION
628
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
628
SCREW , Replaced By: N304017008016
632
WASHER FILTER HOUSING TO CONVERTER HOUSING
636
ELECTRIC CABLE FROM INDUCTIVE PICKUP TO PLUG CONNECTION IN CASE
999
SPRING WASHER CAB FLOOR
999
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
999
NUT BRACKET TO SUPPORT AND TO END PIECE
