Поз.
Артикул
Описание
244
CONSOLE CAB MOUNTING,FRONT
244
CONSOLE PEDESTAL
248
BOW CAB MOUNTING,FRONT
252
STRUT BUMPER,RIGHT
252
STRUT BUMPER,LEFT
256
SCREW APPARATUS SUPPORT TO FRAME
256
SCREW , Replaced By: A9429901304
260
SCREW , Replaced By: N308676014012
260
SCREW SUPPORT TO SIDE MEMBER M 14X45
264
NUT STEERING SUPPORT TO FRAME
264
NUT , Replaced By: N910113014000
268
SCREW , Replaced By: N308676016013
268
SCREW CONSOLE AND STRUT TO FRAME
268
SCREWM 16X18X26X48
268
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X40
272
WASHER SHOCK ABSORBER TO UPPER BEARING BRACKET
276
NUT TORSION BAR TO BEARING BRACKET,5 904661
276
NUT CONSOLE TO SUPPORT
276
NUT , Replaced By: N910113016001
280
BRACKET LEFT BUFFER
284
MOUNTING CAB,LEFT
284
MOUNTING CAB, RIGHT
288
LEVER (TILTING LEVER),CAB
292
BUSHING TILTING LEVER
292
BUSHING TILTING LEVER
296
BUFFER TILTING LEVER
298
BUSHING TILTING LEVER
300
BUSHING ON TOGGLE LEVER,FOR HYDRAULIC CYLINDER
324
MOUNTING CAB TILTING LEVER
328
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
328
SCREW , Replaced By: N308676012012
336
SCREW STABILIZER TO BEARING
344
SCREW VERTICAL TAIL PIPE BEHIND CAB
344
SCREW PARTICLE FILTER M14X1,5X105
360
SCREW BEARING BRACKET TO SIDE MEMBER M 12X50
364
SCREW MOUNTING, TORSION BAR, ON SIDE MEMBER
368
SCREW SUPPORT TO TRANSMISSION M 16X85
372
DOWEL PIN MOUNTING TO CONSOLE
376
LOCK WASHER FITTING TO BRACKET
388
WASHER SPARE WHEEL CARRIER
396
SHIM MOUNTING TO CONSOLE
412
NUT PARTICLE FILTER M14
412
NUT , Replaced By: N910113014001
412
NUT BRACKET TO SIDE MEMBER
999
LOCK PULL TO FASTENER
999
LOCK , Replaced By: N912002008003
999
REPAIR KIT , Replaced By: A3879920003, +002A6208910017, +001A3638910023
