Поз.
Артикул
Описание
121
LINE FROM FOUR-CIRCUIT PROTECTIVE VALVE TO AIR RESERVOIR 9X12 MM, LENGTH AVAILABLE 3000 MM
122
UNION NUT LINE CONNECTION, Replaced By: N000000006239
122
UNION NUT LINE CONNECTION
123
SEAL CONE LINE CONNECTION
123
GLAND , Replaced By: A0019901967
124
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
125
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
125
CLAMP HOSE TO FITTING AND TO OIL TANK
877
VALVE FRONT AND REAR AXLES
877
VALVE (TWO-/TWO-WAY VALVE)
879
VALVE 3/2-WAY VALVE
879
VALVE 3/2-WAY VALVE
881
SCREW PIPE TO CHARGING AIR INTERCOOLER M 10X45
883
WASHER , Replaced By: N000433010510
883
WASHER VIBRATION ABSORBER TO BRACKET
885
FITTING DELIVERY LINE TO PUMP
887
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
889
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
891
VALVE 3/2-WAY VALVE,CONNECTION: "2"
891
VALVE SHUT-OFF VALVE,CONNECTION: "20"
893
SEAL RING LINE CONNECTION
895
VALVE INSERT. VALVE CAP 3/2-WAY VALVE,CONNECTION: "2"
897
VALVE CAP
899
VALVE 3/2-WAY VALVE,CONNECTION: "1"
901
SEAL RING LINE CONNECTION
903
THREADED CONNECTION COMPRESSED AIR LINE TO WHEEL HUB
903
SCREW CONNECTION DELIVERY LINE TO PUMP
903
SCREW CONNECTION COMPRESSED AIR LINE TO WHEEL HUB, Replaced By: N000000006458
905
FITTING COMPRESSED AIR LINE TO WHEEL HUB
907
SEAL RING VALVE TO VALVE,K 025179
909
VALVE FRONT AND REAR AXLES
909
VALVE (TWO-/TWO-WAY VALVE)
911
VALVE 3/2-WAY VALVE
911
VALVE 3/2-WAY VALVE
913
SCREW PIPE TO CHARGING AIR INTERCOOLER M 10X45
915
WASHER , Replaced By: N000433010510
915
WASHER VIBRATION ABSORBER TO BRACKET
917
FITTING DELIVERY LINE TO PUMP
919
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
921
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
923
VALVE 3/2-WAY VALVE,CONNECTION: "2"
925
SEAL RING LINE CONNECTION
927
VALVE INSERT. VALVE CAP 3/2-WAY VALVE,CONNECTION: "2"
929
VALVE CAP
931
VALVE 3/2-WAY VALVE,CONNECTION: "1"
933
SEAL RING LINE CONNECTION
935
SCREW CONNECTION DELIVERY LINE TO PUMP
937
FITTING COMPRESSED AIR LINE TO WHEEL HUB
939
SEAL RING VALVE TO VALVE,K 025179
941
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
943
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
945
HEX. KEY WRENCH. SCREWDRIVER
945
HEX. KEY WRENCH
947
SOCKET WRENCH
949
FITTING BRAKE DRUM TO REAR AXLE SHAFT,5 366362
951
SEAL RING VALVE TO VALVE,K 025179
953
LINE AT FITTING,5 366362
955
SCREW END PIECE TO EXHAUST PIPE M 10X25
957
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
THRUST RING THROTTLE VALVE,CONNECTIONS: "1,2"
999
ELBOW FITTING , Replaced By: A0004294638
999
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
999
MUFFLER , Replaced By: A0004302370
999
MUFFLER BRAKE PRESSURE REGULATOR BREATHING,5 419692
999
REPAIR KIT DIAPHRAGM PART BOSCH,209
999
MUFFLER TRAILER CONTROL VALVE
999
REPAIR KIT PRESSURE LIMIT VALVE
999
REPAIR KIT SEAL RING BOSCH,209
999
SWITCH SUPPLY PRESSURE CONTROL
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
REPAIR KIT , Replaced By: A0004301107
999
ELBOW FITTING , Replaced By: A0049906471
999
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
VALVE (PRESSURE LIMIT VALVE)
999
PRESSURE REGULATORBOSCH
999
PRESSURE REGULATORWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PRESSURE REGULATORKNORR 90310
999
FITTING (DELIVERY LINE),FROM PUMP TO STEERING, Replaced By: A9329970772
999
VALVE (THROTTLE VALVE)
999
ELBOW FITTING CHECK VALVE TO RELAY VALVE
999
SEAL RING THROTTLE VALVE,CONNECTIONS: "1,2"
999
GROMMET 2/2-WAY VALVE,CONNECTION: "1,2",5 548796
999
BRACKET METAL SPRING BELLOWS
999
BRACKET RELAY VALVE, NOT USED
999
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
999
NUT SPRING-LOADED PUSH ROD
999
CLAMP LINE MOUNTING
