Поз.
Артикул
Описание
10
RESERVOIR , Replaced By: A0014327501
10
RESERVOIR , Replaced By: A0034321201
10
RESERVOIR10L,206 MM,8.5 BAR
10
RESERVOIR COMPRESSED AIR 20 L, TO VOSS 232, FOR VEHICLES WITH VOSS 230 CONNECTOR: ADD. MOUNT FITTING "A 004 997 82 72" WITH O-RING "A 000 987 04 46" AND THRUST RING "A 000 997 02 03" TO AIR RESERVOIR
10
RESERVOIR20L,246 MM,12.5 BAR
10
RESERVOIR COMPRESSED AIR,5 295503
10
RESERVOIR , Replaced By: A0034321201
10
RESERVOIR COMPRESSED AIR 20 L
10
RESERVOIR COMPRESSED AIR 30 L
60
RESERVOIR40L,246 MM,8.5 BAR
60
RESERVOIR , Replaced By: A0034322301
60
RESERVOIR40L,276 MM,8.5 BAR
80
RESERVOIR COMPRESSED AIR 10/10 L
107
SUPPORT AIR RESERVOIR TO FRAME
110
SUPPORT AIR RESERVOIR TO REAR CROSS MEMBER, SIMPLE PART-PLEASE HAVE SHOP MADE
140
SCREW , Replaced By: A9429901304
140
SCREW APPARATUS SUPPORT TO FRAME
140
SCREW CONSOLE TO SIDE MEMBER
170
SCREW , Replaced By: N304017008027
170
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
180
NUT , Replaced By: N913004008001
180
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
190
NUT , Replaced By: N910113016001
190
NUT CONSOLE TO SUPPORT
190
NUT SUPPORT TO SIDE MEMBER
190
NUT STEERING SUPPORT TO FRAME
190
NUT , Replaced By: N910113014000
200
SCREW , Replaced By: N304017008040
200
SCREW BRACKET TO SIDE MEMBER
210
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
210
NUT , Replaced By: N913004008001
220
BRACKET AIR RESERVOIR TO FRAME
220
BRACKET AIR RESERVOIR TO FRAME
220
BRACKET AIR RESERVOIR TO FRAME
230
BRACKET AIR RESERVOIR TO APPARATUS SUPPORT
230
BRACKET AIR RESERVOIR TO APPARATUS SUPPORT
240
BRACKET REAR AIR RESERVOIR, NOT USED
250
BRACKET APPARATUS SUPPORT
260
SPACER TUBE 3/2-WAY VALVE TO BRACKET,5 556783
260
BUSHING , Replaced By: A1869913340
270
SCREW STRAP TO BRACKET
280
NUT , Replaced By: N913004008001
280
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
290
SCREW BRACKET TO CROSS CONNECTION STRUT
290
SCREW BRACKET TO CROSS CONNECTION STRUT
290
SCREW BRACKET TO CROSS CONNECTION STRUT
290
SCREW , Replaced By: N304017008034
300
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
300
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
300
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
300
NUT , Replaced By: N913004008001
310
SCREW , Replaced By: N304017008021
310
SCREW , Replaced By: N304017010002
310
SCREW BRACKET TO SIDE MEMBER
310
SCREW PIPE CLAMP
320
WASHER BRACKET TO COVERING
320
WASHER , Replaced By: N009021010209
330
NUT STRAP TO BRACKET
330
NUT , Replaced By: N910113010000
350
STRAP PARTICLE FILTER
350
STRAP AIR RESERVOIR TO BRACKET
350
STRAP , Replaced By: A6554900942
350
STRAP , Replaced By: A6214900242
360
NUT STRAP TO BRACKET
360
NUT , Replaced By: N910113010000
390
VALVE DRAIN, Replaced By: A0004322107
390
VALVE DRAIN, Replaced By: A0004322407
390
VALVE DRAIN, Replaced By: A0004322107
390
VALVE. DRAIN VALVE DRAIN
400
O-RING CHECK VALVE TO AIR RESERVOIR
410
THRUST RING CHECK VALVE TO AIR RESERVOIR
410
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
